9105-41B, 9105-42A, 9786-42H, 9080-HEX, 9782-80H, 9781-50H, or 9786-22H system and EMX0
PCIe3 expansion drawers system and EMX0 PCIe3 expansion drawers (http://www.ibm.com/support/
knowledgecenter/POWER10/p10hcd/p10hcd_pcibyfeature.htm).
The 9043-MRX systems can have two, three, or four system processor modules.
Note: In the following table, the slot priority numbers 1 - 11 correspond to slot locations P0-C1 through
P0-C11.
Table 3. Adapter slot priorities and maximum adapters supported in the 9043-MRX
Feature code Description Slot priority Maximum number of
adapters supported
2 processors 3 processors 4 processors
5899 PCIe2 4-port 1 GbE
adapter (FC 5260, FC
5899, FC EL4L, and FC
EL4M; CCIN 576F)
11, 8, 10, 7, 9, 6, 1 11, 8, 5, 3, 10, 7, 4, 2, 9,
6, 1
11, 8, 5, 3, 10, 7, 4, 2, 9,
6, 1
7/11/11
EC2S PCIe3 2-port 10 Gb NIC
& RoCE SR/Cu adapter
(FC EC2R and EC2S;
CCIN 58FA)
11, 8, 10, 7, 9, 6, 1 11, 8, 5, 3, 10, 7, 4, 2, 9,
6, 1
11, 8, 5, 3, 10, 7, 4, 2, 9,
6, 1
7/11/11
EC2U PCIe3 2-port 25/10 Gb
NIC & RoCE SFP28
Adapter (FC EC2U; CCIN
58FB)
11, 8, 10, 7, 9, 6, 1 11, 8, 5, 3, 10, 7, 4, 2, 9,
6, 1
11, 8, 5, 3, 10, 7, 4, 2, 9,
6, 1
7/11/11
EC5B PCIe3 x8 Non-Volatile
Memory 1.6 TB SSD
NVMe adapter (FC
EC5A, EC5B, EC5G,
EC6U, and EC6V; CCIN
58FC)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EC5D PCIe3 x8 Non-Volatile
Memory 3.2 TB SSD
NVMe adapter (FC EC5C
and EC5D; CCIN 58FD)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EC5F PCIe3 x8 Non-Volatile
Memory 6.4 TB SSD
NVMe adapter (FC
EC5E, EC5F, EC6Y, and
EC6Z; CCIN 58FE)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EC66 2-port 100 GB RoCE En
Connectx-5 PCIe4 x16
adapter (FC EC66; CCIN
2CF3)
11, 8 11, 8, 5, 3, 4, 2 11, 8, 5, 3, 4, 2 2/6/6
EC6K PCIe2 LP 2-Port USB
3.0 Adapter (FC EC6J
and FC EC6K; CCIN
590F); Adapter part
number: 02JD518
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EC7B PCIe4 x8 NVMe 1.6 TB
SSD NVMe Adapter (FC
EC7A, EC7B, EC7J, and
EC7K; CCIN 594A)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EC7D PCIe4 x8 NVMe 3.2 TB
SSD NVMe Adapter (FC
EC7C, EC7D, EC7L, and
EC7M; CCIN 594B)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EC7F PCIe4 x8 NVMe 3.2 TB
SSD NVMe Adapter (FC
EC7E, EC7F, EC7N, and
EC7P; CCIN 594C)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EJ0J PCIe3 SAS RAID quad-
port 6 Gb adapter (FC
EJ0J and EL59); CCIN
57B4)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9 11, 8, 5, 3, 10, 7, 4, 2, 9 6/9/9
Adapter placement for the 9043-MRX 3
