Table 3. Adapter slot priorities and maximum adapters supported in the 9043-MRX (continued)
Feature code Description Slot priority Maximum number of
adapters supported
2 processors 3 processors 4 processors
EJ14 PCIe3 12 GB Cache
RAID PLUS SAS adapter
quad-port 6 Gb x8 (FC
EJ14; CCIN 57B1)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9 11, 8, 5, 3, 10, 7, 4, 2, 9 6/9/9
EJ2A PCIe4 cable adapter (FC
EJ2A; CCIN 6B99)
10, 7, 11, 8 10, 7, 11, 8, 5, 3, 4, 2 10, 7, 11, 8, 5, 3, 4, 2 4/8/8
EJ32 4767-001
Cryptographic
Coprocessor (FC EJ32;
CCIN 4767)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9 11, 8, 5, 3, 10, 7, 4, 2, 9 6/10/10
EJ35 4769-001
Cryptographic
Coprocessor (FC EJ35
and EJ37 for BSC; CCIN
C0AF)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EN0S PCIe2 4-port (10 Gb + 1
GbE) SR+RJ45 adapter
(FC EN0S; CCIN 2CC3)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/11/11
EN0U PCIe2 4-port (10 Gb + 1
GbE) Copper SFP+RJ45
adapter (FC EN0U; CCIN
2CC3)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/11/11
EN0W PCIe2 2-port 10 GbE
BaseT RJ45 adapter (FC
EN0W; CCIN 2CC4)
11, 8, 10, 7, 9, 6, 1 11, 8, 5, 3, 10, 7, 4, 2, 9,
6,1
11, 8, 5, 3, 10, 7, 4, 2, 9,
6,1
7/11/11
EN1A PCIe3 8x 2-port Fibre
Channel (32 Gb/s); (FC
EL5U, EL5V, EN1A, and
EN1B); CCIN 578F)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EN1C PCIe3 8x 4-port Fibre
Channel (16 Gb/s); (FCs
EL5W, EL5X, EN1C, and
EN1D; CCIN 578E)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EN1E PCIe3 x8 4-port Fibre
Channel (16 Gb/s);
(EN1F; CCIN 579A);
Adapter part number:
02JD586
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EN1G PCIe3 8x 2-port Fibre
Channel (16 Gb/s)
(EN1G and EN1H; CCIN
579B); Adapter part
number: 02CM900 and
02CM903
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EN1J PCIe4 x8 2-port Fibre
Channel (32 Gb/s);
(EN1K; CCIN 579C);
Adapter part number:
02CM909
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
EN2A PCIe3 16 Gb 2-port
Fibre Channel adapter
(FC EN2A and FC EN2B;
CCIN 579D)
11, 8, 10, 7, 9, 6 11, 8, 5, 3, 10, 7, 4, 2, 9,
6
11, 8, 5, 3, 10, 7, 4, 2, 9,
6
6/10/10
4 Power Systems: Adapter placement for the 9043-MRX
