7109 or 5889 PDU+
Table 131. 7109 or 5889 PDU+ features
PDU Number Racks usage Supported power cords (PDU to wall)
7109 or 5889 PDU+ 7953-94X, 7965-94Y, 0551, 0553,
and 0555 IBM racks
“Supported PDU power cords” on page 105
Table 132. 7109 PDU+ specifications
Characteristics Properties
PDU number 7109
Height 43.9 mm (1.73 in.)
Width 447 mm (17.6 in.)
Depth 350 mm (13.78 in.)
Additional clearance 25 mm (0.98 in.) for circuit breakers
3 mm (0.12 in.) for outlets
Weight (not including power cord) 6.3 kg (13.8 lb)
Weight of power cord (approximate) 5.4 kg (11.8 lb)
Operating temperature at 0 - 914 m (0 - 3000
ft) (room ambient)
10°C - 32°C (50°F - 90°F)
Operating temperature at 914 - 2133 m (3000 -
7000 ft) (room ambient)
10°C - 35°C (50°F - 95°F)
Operating humidity 8% - 80% (noncondensing)
Localized air temperature in PDU 60°C (140°F) maximum
Rated frequency (all feature codes) 50 - 60 Hz
Circuit breakers Six double-pole branch rated circuit breakers that are rated at 20 A
Power outlet 12 IEC 320-C13 outlets that are rated at 10 A (VDE) or 15 A
(UL/CSA)
7196 PDU+
Table 133. 7196 PDU+ features
PDU Number Racks usage Supported power cords (PDU to wall)
7196 PDU+ 7014-B42 Fixed power cord with IEC 60309, 3P+E, 60 A plug
Table 134. 7196 PDU+ specifications
Characteristics Properties
PDU number 7196
Height 43.9 mm (1.73 in.)
Width 447 mm (17.6 in.)
Depth 350 mm (13.78 in.)
Additional clearance 25 mm (0.98 in.) for circuit breakers
3 mm (0.12 in.) for outlets
Weight (not including power cord) 6.3 kg (13.8 lb)
Weight of power cord (approximate) 5.4 kg (11.8 lb)
114 Site and hardware planning
