Table 143. SAS cable labeling (continued)
Name Connects Label
SAS 4x EE cable One disk expansion drawer to
another disk expansion drawer in a
cascaded configuration
SAS AA cable SAS adapter to SAS adapter
SAS YO cable SAS adapter to a disk expansion
drawer
SAS X cable Two SAS adapters to a disk
expansion drawer in a RAID
configuration
SAS YI cable System external SAS port to a disk
expansion drawer
Site and hardware planning 127
