IBM Power Systems Series Site And Hardware Planning

8. Four independent SAS adapters to one ESLL or ESLS storage enclosure through a mode 4 connection.
v For SAS adapter pairs, you must attach the cables to the same port on both adapters.
v Connection by using SAS X12 cables to connect to the ESLL or ESLS storage enclosure.
v Supported only on AIX and Linux systems.
Figure 101. Mode 2 connection of one ESLL or ESLS storage enclosure by using X12 cables to two pairs of SAS
adapters
Site and hardware planning 171

IBM Power Systems Series Specifications

General

Virtualization	PowerVM
Architecture	POWER
Operating System	AIX, IBM i, Linux
Use Case	Enterprise workloads, cloud
Form Factor	Rack-mount
I/O	PCIe
Power Supply	Redundant power supplies available
Management	HMC (Hardware Management Console)
Processor	IBM POWER processors (POWER9, POWER10, etc.)
Storage	Supports various storage options including SSDs and HDDs
