IBM SAN24B-6 Product Guide

8 IBM Storage Networking SAN24B-6 Switch
Table 2 lists the management specifications for the SAN24B-6 switch.
Table 2 Management features
Port speed 4, 8, and 16 Gbps when using 16 Gbps SFP+ transceivers
8, 16, and 32 Gbps when using 32 Gbps SFP+ transceivers
USB One USB port for system log file downloads or firmware upgrades
Fabric services
Note: Some fabric services do
not apply or are unavailable in
Access Gateway mode.
򐂰 Monitoring and Alerting Policy Suite (MAPS)
򐂰 Flow Vision
򐂰 Adaptive Networking (Traffic Isolation, quality of service)
򐂰 Fabric Performance Impact (FPI) Monitoring
򐂰 Slow Drain Device Quarantine (SDDQ)
򐂰 Advanced Zoning (default zoning, port/WWN zoning, broadcast
zoning, peer zoning, target-driven zoning)
򐂰 Dynamic Fabric Provisioning (DFP)
򐂰 Dynamic Path Selection (DPS)
򐂰 Extended Fabrics
򐂰 Enhanced BB credit recovery
򐂰 FDMI
򐂰 Frame Redirection
򐂰 Frame-based Trunking
򐂰 FSPF
򐂰 ISL Trunking
򐂰 Management Server
򐂰 NPIV
򐂰 NTP v3
򐂰 Registered State Change Notification (RSCN)
򐂰 Reliable Commit Service (RCS)
򐂰 Simple Name Server (SNS)
򐂰 Virtual Fabrics (Logical Switch, Logical Fabric)
򐂰 Read Diagnostics Parameter (RDP)
򐂰 VM Insight
a. You will need to choose one of the 2445, 2446, or 2447 optional feature codes.
Supported management
software
򐂰 HTTP, SNMP v1/v3 (FE MIB, FC Management MIB), SSH
򐂰 Auditing, Syslog
򐂰 Advanced Web Tools
򐂰 IBM Network Advisor SAN Enterprise or IBM Network Advisor
Professional Plus
򐂰 CLI
򐂰 SMI-S compliant
򐂰 Administrative Domains
򐂰 Trial licenses for add-on capabilities

IBM SAN24B-6 Specifications

General

Ports	24
Form Factor	1U
Switch Class	Enterprise
Power Supply	Dual, hot-swappable
Fabric OS	Brocade Fabric OS
Redundancy	Yes
Management	Web Tools
