IBM SAN24B-6 Product Guide

10 IBM Storage Networking SAN24B-6 Switch
Table 5 lists the electrical characteristics of the SAN24B-6 switch.
Table 5 Electrical characteristics
Table 6 lists the available optional features.
Table 6 Optional features
Storage altitude Up to 12 km (39,370 ft)
Shock Operating: Up to 20 G, 6 ms half-sine
Non-operating: Half sine, 33 G 11 ms, 3G axis
Vibration Operating: 0.5 g sine, 0.4 grms random, 5 Hz to 500 Hz
Non-operating: 2.0 g sine, 1.1 grms random, 5 Hz to 500 Hz
Heat dissipation 24 ports at 215 BTU per hour
Power supply Base switch includes a single, fixed power supply with four
integrated system cooling fans
AC input 90 V - 264 V
Maximum input current 2.2 A
Input line frequency 47 Hz - 63 Hz
Power consumption 76.52 W with all 24 ports populated with 32 Gbps SWL optics 55.83
W for idle configuration (all optics loaded but not initialized)
Feature code Feature name Feature description
2445 F24 Zero SFP Bundle This feature enables FC ports 0 to 7. It does not
include SFP transceivers.
2446 F24 8 x 16Gbps SW SFP
Bundle
This feature provides a bundle of eight SW 16 Gbps
SFPs transceivers with 8 FC ports enabled.
2447 F24 16Gbps SW SFP
Enterprise Bundle
This feature provides a bundle of 24 SW 16 Gbps
SFP transceivers with 24 FC ports enabled.
7422 SAN24B-6 Enterprise
Bundle
This feature enables the following: Trunking
Activation, Extended Fabric, and Fabric Vision.
7498 SAN24B-6 8 Port 16Gbps
SW Upgrade
This feature enables additional port activation for
ports 8 to 15 (first eight port increment) or ports 16
to 23 (second eight port activation). Note that the
first port is designated as port zero and the last port
is designated as port 23. It includes eight 16 Gbps
SW SFP transceivers.
7499 Gen 6 8 Port Activation This feature enables additional port activation for
ports 8 to 15 (first eight port increment) or ports 16
to 23 (second eight port activation). Note that the
first port is designated as port zero and the last port
is designated as port 23. This feature does not
include SFPs.
