IBM System Storage TS3100 and TS3200 Tape Libraries 5
these t
y
pes of applications. The IBM Ultrium WORM cartrid
g
es work with the IBM S
y
stem Stora
g
e LTO
Ultrium Tape Drives to help prevent the alteration or deletion of user data. In addition, IBM has taken
several steps to reduce the possibility of tampering with the information:
The bottom of the cartridge is molded in a different color than rewritable cartridges.
z
The special cartridge memory helps protect the WORM nature of the media.
z
A unique format is factory-written on each WORM cartridge.
z
Table 2 lists the cabling ordering information for the TS3100 and TS3200.
Table 2. TS3100 and TS3200 cabling ordering information
Cables Part number
4.5 m VHDCI/HD68 SCSI Cable 23R7134
10.0 m VHDCI/HD68 SCSI Cable 23R7135
13.0 m LC/LC Fibre Cable 23R7137
25.0 m LC/LC Fibre Cable 23R7138
LC-SC Fibre Cable Interposer 23R7140
2M SAS/Mini-SAS 1x Cable 95P4711
2M Mini-SAS/Mini-SAS 1x Cable 95P4713
SAS/Mini-SAS 4x Interposer 95P4994
Mini-SAS/Mini-SAS 4x Interposer 95P4996
Table 3 lists the common specifications for the TS3100 and TS3200.
Table 3. TS3100 and TS3200 specifications
Specifications
Tape drive type IBM Ultrium LTO-5 Full-High and Half-High
z
IBM Ultrium LTO-4 Full-High and Half-High
z
IBM Ultrium LTO-3 Half-High
z
Tape drive physical capacity Up to 3.0 TB per cartridge compressed; 1.5 TB native with LTO-5 media
z
Up to 1.6 TB per cartridge compressed; 800 GB native with LTO-4 media
z
Up to 800 GB per cartridge compressed; 400 GB native with LTO-3 media
z
Data transfer rate (per drive) Up to 140 MBps native with LTO-5 tape drive
z
Up to 120 MBps native with LTO-4 tape drive
z
Up to 80 MBps native with LTO-3 tape drive
z
Attachment support 8 Gbps fibre channel and 6 Gbps SAS interfaces
z
LVD SCSI (LTO-4 Full-High)
z
4 Gbps fibre channel and 3 Gbps SAS interfaces (LTO-4 Full-High)
z
Warranty Three-year, customer-replaceable unit (CRU) service in most countries
Operating environment
Temperature 50 to 113 degrees F (10 to 45 degrees C)
Relative humidity 10% RH to 80% RH (non-condensing)
Electrical power 4.0 amps at 100 V ac; 2.0 amps at 240 V ac 0.1 KVA

IBM System Storage TS3100 Specifications

General

Number of Tape Drives	1
Number of Tape Cartridges	24
Product Type	Tape Library
Operating Humidity	20% to 80% non-condensing
Interface	SAS
Supported Tape Drive Types	LTO Ultrium 5, LTO Ultrium 6
Tape Drive Technology	LTO Ultrium
