IBM System Storage TS3100 and TS3200 Tape Libraries 7
Table 5 lists the unique specifications for the TS3200.
Table 5. TS3200 unique specifications
TS3200 specifications
Number of drives Up to 2 Full-Highs or up to 4 Half-Highs
Number of tape
cartridges
48
Number of mail slots 3
Library physical
capacity
Up to 144 TB per tape library compressed; 72 TB native with Ultrium LTO-5 media
z
Up to 76.8 TB per tape library compressed; 38.4 TB native with Ultrium LTO-4 media
z
Up to 38.4 TB per tape Library compressed; 19.2 TB native with Ultrium LTO-3 media
z
Dimensions (W x H x D)
Stand-alone 17.6 in (447.5 mm) x 7.29 in (185.2 mm) x 31.9 in (810 mm)
Rack-mount 17.6 in (447.5 mm) x 6.89 in (175.2 mm) x 29.13 in (740 mm)
Weight 47 lb. (21.3 kg) without rack mount
What’s in the TS3200 shipping box?
The box contains the following items:
Tape Library Model L4U Driveless
z
12 data cartridge left upper magazine
z
12 data cartridge left lower magazine
z
Two 12 data cartridge right magazines
z
IBM Ultrium Drives (ordered separately)z
Power Cord (must be selected)z
One IBM Ultrium Cleaning Cartridge (universal)z
IBM System Storage TS3100/TS3200 Tape Setup, Operator and Service Guide
z
IBM System Storage TS3100/TS3200 Tape Library Installation Quick Reference
z
Quality Hotline Cardz
Device Driver readme sheetz
Safety pointer multi-language readme sheetz
License Agreement for Machine Codez
NLS Translated Safety CDz
Misc Documents CDz

IBM System Storage TS3100 Specifications

General

Number of Tape Drives	1
Number of Tape Cartridges	24
Product Type	Tape Library
Operating Humidity	20% to 80% non-condensing
Interface	SAS
Supported Tape Drive Types	LTO Ultrium 5, LTO Ultrium 6
Tape Drive Technology	LTO Ultrium
