IBM THINKPAD X40 Hardware Maintenance Manual

v Each FRU is available for all types or models, unless
specific types or models are specified.
v A CRU (customer-replacable unit) is identified by a
single asterisk (*) or two asterisks (**) in the CRU ID
column. An N in the CRU ID column means that the part
is not a CRU. A single asterisk (*) means that the part is
a Tier 1 CRU; two asterisks (**) mean that the part is a
Tier 2 CRU.
Tier 1 CRU:
(Example:
Mouse, external keyboard, and hard-disk
drive with coin screw)
– NO TOOLS ARE REQUIRED.
– A coin or a thumb screw is acceptable.
– Minimal technical expertise is required.
– Minimal problem determination is required—less than
5 minutes.
Tier 2 CRU:
(Example:
Adapter card, ThinkPad memory)
– Up to 4 screws or fasteners have to be removed.
– Some technical experience is required.
– HelpCenter assistance may be used.
– Problem determination can be done by the customer,
either on site or with HelpCenter assistance.
v
FRUs marked with OP are available as options.
No. FRU P/N CRU
ID
1 LCD unit (see “LCD FRUs” on page 128).
2 Keyboard bezel (Upper case with cover
switch cable, PCMCIA door, and IBM
logo)
13N5313 N
3 Hard disk drive w/ tray & screws 20GB
(Hitachi)
v 2371-13x, 14x, 15x, 16x, 1Cx, 1Dx,
1Rx
v 2386-13x, 1Cx, 1Qx, 1Zx
v 2371-4VM, 4WM, 4VB, 4WB, 4VH,
4WH, 4VJ, 4WJ, 4VV, 4WV
92P6083 *
(continued)
Parts list
122 ThinkPad X40 (2369, 2370, 2371, 2372, 2382,
2386)
