IBM System x3200 M3 15
The following table lists the RAID controllers and additional options used for internal disk storage of x3200
M3 server.
Table 7. RAID controllers for internal storage
Part
number
Feature
code
Description Maximum
supported
Where
used
81Y4492 A1XL ServeRAID H1110 SAS/SATA Controller 1 -
49Y4731 9742 ServeRAID-BR10il SAS/SATA Controller v2 1 42x, 52x,
62x, C2x
46M0831 0095 ServeRAID M1015 SAS/SATA Controller 1 -
46M0832 9749 ServeRAID M1000 Series Advance Feature Key 1 -
46M0916 3877 ServeRAID M5014 SAS/SATA Controller 1 -
46M0829 0093 ServeRAID M5015 SAS/SATA Controller 1 -
46M0917 5744 ServeRAID M5000 Series Battery Kit 1 -
46M0930 5106 ServeRAID M5000 Series Advanced Feature Key* 1 -
81Y4426 A10C ServeRAID M5000 Series Performance Accelerator Key* 1 -
* Note: The Advanced Feature Key and Performance Accelerator Key cannot be used at the same time. Only one
key can be installed onto the RAID controller.
The ServeRAID BR10il v2 RAID controller and ServeRAID H1110 occupy the dedicated PCI-E slot on
x3200 M3 and does not consume regular PCI expansion slots. However, M1015, M5014, M5015, and
MR10i RAID controllers occupy one of the standard PCI Express x8 Gen 2 slots, therefore limiting the
maximum number of additional I/O adapter slots to 4. Only one RAID controller can be used with the
server to support internal HDDs.
The ServeRAID H1110 SAS/SATA Controller has the following specifications:
Four internal 6 Gbps SAS/SATA ports

One x4 mini-SAS internal connector (SFF-8087)

6 Gbps throughput per port

Based on LSI SAS2004 6 Gbps RAID on Chip (ROC) controller

x4 PCI Express 2.0 host interface

Supports RAID 0, 1, 1E, and 10

Supports up to two integrated volumes

Supports up to two global hot-spare drives

Supports drive sizes greater than 2 TB for RAID 0, 1E, and 10 (not RAID 1)

Fixed stripe size of 64 KB

The ServeRAID BR10il v2 SAS/SATA Controller has the following specifications:
One Mini-SAS internal connector

Supports RAID levels 0, 1, and 1E

3 Gbps throughput per port

Based on the LSI 1064E controller

PCI Express 2.0 x4 host interface

Stripe size: 64 KB (fixed)


IBM X3200 M3 Specifications

General

Server type	Tower
Chipset	Intel 3420
Max Memory	32 GB
Storage Controller	Integrated SATA controller
Expansion Slots	2 x PCIe x8, 1 x PCIe x4, 1 x PCI
Network	Integrated dual Gigabit Ethernet
CPU	Intel Xeon 3400 series
Memory type	DDR3
RAID Support	RAID 0, 1, 10
Operating System Support	Windows Server, Red Hat, SUSE
