IBM System x3200 M3 22
The optional virtual media key is required to enable the remote presence and blue-screen capture
features. The remote presence feature provides the following functions:
Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz, regardless of the system

state
Remotely accessing the server, using the keyboard and mouse from a remote client

Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote client, and mapping

ISO and diskette image files as virtual drives that are available for use by the server
Uploading a diskette image to the IMM memory and mapping it to the server as a virtual drive

The blue-screen capture feature captures the video display contents before the IMM restarts the server
when the IMM detects an operating-system hang condition. A system administrator can use the
blue-screen capture to assist in determining the cause of the hang condition. The following table lists the
remote management option.
Table 13. Remote management option
Part
number
Feature
code
Description Maximum quantity
supported
46C7527 5891 IBM Virtual Media Key For Entry Systems 1
Physical and electrical specifications
Height: 438 mm (17.25 in)

Width: 216 mm (8.5 in)

Depth: 540 (21.25 in)

Weight::

Minimum ship configuration: 16.3 kg (36.0 lb)

Maximum ship configuration: 25.2 kg (56.0 lb)

Supported environment:
Temperature

Server on

10.0° to 35.0° C (50° to 95° F); altitude: 0 to 914.4 m (3,000 ft)

10.0° to 32.0° C (50° to 89.6° F); altitude: 914.4 m (3,000 ft) to 2,133.6 m (7,000 ft)

Server off

10.0° to 43.0° C (50° to 109.4° F); maximum altitude: 2,133.6 m (7,000 ft)

Shipping

-40° to 60° C (-40° to 140° F)

Relative humidity: 8% to 80%

Maximum altitude: 2,133.6 m (7,000 ft)

