IC Audio AMP 480 - Page 16

POWER INPUT:350WATTSPOWER INPUT:350WATTS
POWER INPUT:350WATTSPOWER INPUT:350WATTS
REMOTE START
LINE
MIC
SENS
AMP 120/240(480)
MIC/LINE
ic audio
On the rear side of your amplifier you can connect
your microphone or any music source in the plug
of MIC/LINE (it is symmetric). The input is
adjustable.
XLR-INPUT
1
2
3
Tip: HOT (Signal)
Ring: COLD (Signal)
Ground: GND
1/4” Jack Plug
GROUND RING TIP
6.35 mm Stereo
Device Functions
- Rear side -
1: SCREEN
2: HOT
3: COLD
16
EN
MIC/LINE
