ic audio
EV-5000
EN
21
Key 3 Audio and Relay Programming
It must be pointed out, that sources which are not allocated to a zone and have no line relay
activated, will not be shown in that screen.
Key 4 Miscellaneous Settings
Key 5 Text Input
After entering a key number and changing the label ZONE 1 (12 characters maximum) for instance
the following appears:
SOURCE |L1|L2|L3|L4| |R1|R2|R3|R4|
EV-P2/4 01|**| | | | | | | | |
EV-P2/4 02| |**| | | | | | | |
EV-P2/4 03| | |**| | | | | | |
EV-P2/4 04| | | |**| | | | | |
ALARM 1 |**|**|**|**| | | | | |
ALARM 2 |**|**|**|**| | | | | |
MESSAGE |**|**|**|**| | | | | |
CHIME |**|**|**|**| | | | | |
AUX |**|**|**|**| | | | | |
FIRE MIC1 |**|**|**|**| | | | | |
FIRE MIC2 |**|**|**|**| | | | | |
PAGE/P8 GC|**|**|**|**| |**|**| | |
PAGE/P8 01|**| | | | | |**|**|**|
PAGE/P8 02| |**| | | |**| |**|**|
PAGE/P8 03| | |**| | |**|**| |**|
PAGE/P8 04| | |**| | |**|**|**| |
CHIME ON
MUSIC ON
SHORT TO EARTH 4I3I2I1I
IMPEDANCE 4I3I2I1I
SHORT CIRCUIT 4I3I2I1I
OPEN LINE 4I3I2I1I
SWITCH1-4 = ALARM1-4
NORMAL 007
TEXT INPUT:
LINE 1 KEY 1
LINE 2 KEY 2
LINE 3 KEY 3
LINE 4 KEY 4
TEXT INPUT:
STOCK 1 KEY 1
LINE 2 KEY 2
LINE 3 KEY 3
LINE 4 KEY 4
TEXT INPUT: ...DONE
