The PC readouts in detail:
Key 1 Installed components
Key 2 Audio level
EV5000
KEY 1 : installed components
KEY 2 : Audio level
KEY 3 : Audio and Relaisprogramming
KEY 4 : Misc. Setting
KEY 5 : Text input
KEY 6 : Errors
KEY 7 : Factory Setting
Caution !! Delets all Settings
INSTALLED COMPONENTS
ALARM 1 3.3V
ALARM 2 3.3V
FIRE MIC1 3,4V COIL :INSTALLED
FIRE MIC2 3,3V COIL :INSTALLED
PAGE/P8 2 3
AMP: 1 LINE : 1 :030 032
AMP: 2 LINE : 2 :038 035
AMP: 3 LINE : 3 :036 033
AMP: 4 LINE : 4 :035 036
SPARE AMP INSTALLED
BATT.VOLTAGE :24V
LEVEL ZONE1 ZONE2 ZONE3 ZONE4
MUSIC |-06 dB |-06 dB |-06 dB |-06 dB |
MUSIC MA |-12 dB |-12 dB |-12 dB |-12 dB |
CHIME |-16 dB |-16 dB |-16 dB |-16 dB |
MESSAGE |-06 dB |-06 dB |-06 dB |-06 dB |
AUX |-06 dB |-06 dB |-06 dB |-06 dB |
VOLUME | 10 dB | 10 dB | 10 dB | 10 dB |
BASS | 00 dB | 00 dB | 00 dB | 00 dB |
TREBLE | 00 dB | 00 dB | 00 dB | 00 dB |
EV-P2/4 |-06 dB |-06 dB |-06 dB |-06 dB |
PAGE/P8 |-06 dB |-06 dB |-06 dB |-06 dB |
ALARM 1 |-06 dB |-06 dB |-06 dB |-06 dB |
ALARM 2 |-06 dB |-06 dB |-06 dB |-06 dB |
FIRE MIC |-06 dB |-06 dB |-06 dB |-06 dB |
