13
Press # Key
Press # Key
BAUD RATE
9 6 0 0
PARITY
N O N E
STOP BIT
O N E
Press # Key
Press # Key
Press # Key
Press # Key
FAVOURITE PAGE
ENERGY
LCD POWER SAVE
ENABLED
ENERGY SELECTION
kVAh/kWh
ENERGY CLEAR OK
Parity setting for Modbus communication
(None, even & odd-can be selected when shift key
or increment key pressed)
For Modbus communication
(One & two can be selected when shift key or
increment key pressed)
Start-up page can be selected
(Energy,
voltage, current & power can be selcted when shift
key or increment key pressed)
LCD Power save Enabled/Disabled is selected
using Shift or Increment key and pressing
Enter key.
(If it is Enabled, then backlit is automatically
switched off when there is no any key press for 3 minutes.
Pressing any key will make backlit ON. If LCD power save
is Disabled, then backlit is switched on permanently)
kWh Energy Reset.
(pressing Enter key
resets energy & Run Hour and displays
“DONE”
in Bottom Row)
Again pressing Index (#) key repeats the same process in cyclic
manner. Press
&
keys (Shift & Increment) together for few
seconds to quit program mode & return to RUN mode.
User can change the Energy
(kVAh / kWh)
Baud rate setting for communication speed
(Range : 9600 / 19200)
