Icegame ROUND-UP - Page 17

17
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#RC2051X - SENSOR HARNESS #RC2013X - ASY (SENSOR)
DRAWN BY
MMARTIN
FILENAME
RC.VSD
PAGE
2 OF 21
REVISED
3/15/02
TITLE
ROUND CRANE
1 2 3 4
4 PIN PLUG #2099 SOLID PIN #2100S
1 2 3 4 5
5 PIN AMP HOUSING #2419 CONTACT PIN #2201
M
#2909
.187
M
#2909
.187
M
#2909
.187
M
#2909
.187
Right Limit Sense
GND
Left Limit Sense
yellow/green black/white yellow/orange
yellow/green
black/white black/white
yellow/orange
4 "
128 " 132 "
To Right Sensor To Left Sensor
PX4
P3
#RC2051X - SENSOR HARNESS
* Twist together 132 " cut 4 " off yellow/ green and black/white on P3 end Use the 4 " of black/white for jumper in harness
#651
.187
#651
.187
#RC2013X - ASY (SENSOR)
#CG2013
#651
.187
#651
.187
#RC2013X - ASY (SENSOR)
#CG2013
* Use existing length of wire * Use existing length of wire
