Icegame ROUND-UP - Page 19

19
DATE
7/9/01
DESCRIPTION
#RC2052X - MAIN/ROTARY HARNESS
DRAWN BY
MMARTIN
FILENAME
RC.VSD
PAGE
4 OF 21
REVISED
3/15/02
TITLE
ROUND CRANE
1 2 6 9
10 12 13 14
3 4 5 7 8
11 15
15 PIN PLUG #2144 SPLIT PIN #2100
BROWN RED BROWN YELLOW BLUE BLUE red brown green black blue white
Motor Up
Motor Down
Claw -
Motor Bk
Motor Lt
Motor Fd
Claw +
Home L/R
Claw Up
Claw Down
Ground Ground
Home F/B
36v
Motor Up Motor Down Motor Bk Motor Fd EARTH Claw - Home L/R Claw Up Claw Down Ground Claw + Home F/B
BROWN
RED
YELLOW
BLUE
GREEN/YELLOW
BROWN
red
brown
green
black + blue
BLUE
white
GREEN/YELLOW
#2997-2 CONDUCTOR
POWER CORD
TO MAIN PCB
P1
CARRAGE
TO ROTARY
HARNESS
TO FRAME
#652
3" STRIP
MAIN TO ROTARY HARNESS
TWISTED WIRE TWISTED WIRE
D C
B A
4321
D C
B A
4321
-12 "
142 "
3" STRIP
142 " 142 "
* Untwist GREEN/YELLOW 21" Cut Off 12 " of GREEN/YELLOW (P1 end)
1 2 8
10 12
6 3 4 5 7
11
9
12 PIN PLUG #2106 SPLIT PIN #2100
