DATE
7/9/01
DESCRIPTION
RC2059X - REMOTE HARNESS
DRAWN BY
MMARTIN
FILENAME
RC.VSD
PAGE
8 OF 21
REVISED
3/15/02
TITLE
ROUND CRANE
1 2 3 4 5 6
6 PIN PLUG #2173 SOLID PIN #2100S
Ground
Program
Account
Ground
Audio Top
Audio Pot
black black/blue white/gray black red/white red/black
Program Switch
32 " 33 " 31 " 34 " 34 " 34 "
2 "
Account Switch Volume Control
P2
