#RC2060X - OPTO HARNESS
DRAWN BY
MMARTIN
FILENAME
RC.VSD
PAGE
9 OF 21
REVISED
3/15/02
TITLE
ROUND CRANE
1 2 3
3 PIN PLUG #2206 SOLID PIN #2100S
1 2 3
3 PIN PLUG #2206 SOLID PIN #2100S
P4
orange green/black black
+12
Prize
Ground
TO MAIN PCB TO OPTO PCB
25 "
orange
green/black
black
