DATE
7/9/01
DESCRIPTION
#RC2063X - COUNTER HARNESS
DRAWN BY
MMARTIN
FILENAME
RC.VSD
PAGE
10 OF 21
REVISED
3/15/02
TITLE
ROUND CRANE
brown/white orange brown
PCNTR
+5v
CCNTR
P8
Counter
TO MAIN PCB
#2558 #2558 #2558
24 "
10 "
* USE NEW LARGE 5V COUNTERS
1 2 3
3 PIN PLUG #2206 SOLID PIN #2100S
0000000000
black red
5v COUNTER
#HD20224
0000000000
black red
5v COUNTER
#HD20224
#2558
