Icegame ROUND-UP - Page 29

29
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#RC2078X - DOOR INTERLOCK HARNESS
DRAWN BY
MMARTIN
FILENAME
RC.VSD
PAGE
14 OF 21
REVISED
3/15/02
TITLE
ROUND CRANE
#653 #653
#651
.187
#651
.187
1
2
34
SOLID STATE
RELAY
#RLDA-
240/15-000
#2111
+
-
#8489 - SWITCH WIDE GAP
+ 12VDC
Door
dome light
GND
yellow/black
black
orange/black
violet/black
48 "
158 "
48 "
9 PIN PLUG #2292 SOLID PIN #2100S
1 2 3 4 5 6 7 8 9
orange/black yellow/black violet/black black
P7
