Name
Function
Name
Function
Power Switch
Turn ON / Off Robot
Button Enter / Menu
Enter menu
LCD Display
Show Menu Panel
Button UP L
Next Menu
Servo Lift
Connector to Servo Gripper
Button Down L
Prev. Menu
Servo Grip
Connector to Servo Gripper
Button ESC / Start
Back to Prev. Menu /
Runnig Robot
USB Connector
Update Firmware /
Programming
Button UP R
Increase Value
Driver Motor
Motor Controller
Button Down R
decrease Value
Battery
Robot Power Supply
Button Re-Start
Restart Robot
ICHIBOT LINE FOLLOWER ULTIMATE 4S
OVERVIEW
