ICM Controls ICM450A User Manual

Parameters
Parameter Description Range Default Recommended
Line Voltage Average phase to phase line voltage 190-600 208 Nameplate Voltage
Delay on Break Amount of time between the load de-energizing and re-energizing 0-10 minutes .1
minute
4 minutes**
Delay on Fault Amount of time before the load de-energizes due to a non-critical fault* 0-15 seconds 15
seconds
7-8 seconds**
% Over/Under
Voltage
Maximum/minimum phase to phase average voltage, respectively 2-25% 20% 12-15%**
% Phase Unbalance Amount of allowable voltage unbalance 2-20% 20% 4-5%**
Reset Mode 0 (auto) or number of times the load can be re-energized after a load side fault before a manual reset is
necessary
0 (auto) , 1-10 0 (auto) 0 (auto)
Control Mode With control mode set to OFF, the load will energize if no 3- phase fault conditions exist; with control mode ON,
the load will energize if no fault conditions exist and control voltage is present at terminals 4 and 5 of the ICM450A
ON or OFF ON Based on wiring
Date and Time Provides real time clock for date and time stamp (ICM450A PLUS+ models) ON or OFF ON ON
Language Set to English or Spanish language for display EN or SP EN English
* Non-critical faults are faults such as high/low voltage and phase unbalance. Critical faults, such as phase loss and phase reversal, have a fault interrogation and typical response time of
under 4 seconds and it is not user adjustable.
** For best recommendations, consult manufacturer of equipment.
Troubleshooting
Problem
LCD
Readout
LED Status Corrective Action
Load will not energize Phase Average All LEDs Off Conrmthatthecontrolinput(terminals4&5)isproperlyconnectedandcongured
Load will not energize Phase Average Load LED Off,
Fault LED blinking
Press FAULToncetoobservethecurrentfault;correcttheconditionoftherstfaultthatappears
(see Fault Conditions above, for a list of corrective actions)
Fault LED blinks repeatedly
while load is energized
Phase Average Fault LED Blinking,
Load LED On
Indicates there are faults saved in the memory, press FAULT rapidly to scroll through saved faults; to clear
the faults, press and hold FAULT for more than 5 seconds
Load will not de-energize
when control voltage is OFF
Phase Average Load LED On,
Control LED Off
The control mode setting is OFF; press SETUP to get to the control mode. Press to set the control
mode ON
Setup LED is on while load
is being energized
Anything Other Than
Phase Average
Setup LED On,
Load LED On
To exit the setup mode, press either READ or FAULT
Load will not energize Reset Fault LED Blinking Unit is in lockout, maximum number of retries in manual reset mode has been reached. To reset the
control, remove and reset power to the control.
Load turns ON and OFF
repeatedly
Readout is Irrelevant Fault LED Blinking Fix load side fault; press FAULT to observe condition; the delay on break period may be too short; press
SETUP to enter the delay on break mode; press to lengthen the delay
ONE-YEAR LIMITED WARRANTY
The Seller warrants its products against defects in material or workmanship for a period of one (1) year from
the date of manufacture. The liability of the Seller is limited, at its option, to repair, replace or issue a non-case
credit for the purchase prices of the goods which are provided to be defective. The warranty and remedies set
forth herein do not apply to any goods or parts thereof which have been subjected to misuse including any use or
applicationinviolationoftheSeller’sinstructions,neglect,tampering,improperstorage,incorrectinstallationor
servicing not performed by the Seller. In order to permit the Seller to properly administer the warranty, the Buyer
shall: 1) Notify the Seller promptly of any claim, submitting date code information or any other pertinent data as
requested by the Seller. 2) Permit the Seller to inspect and test the product claimed to be defective. Items claimed
to be defective and are determined by Seller to be non-defective are subject to a $30.00 per hour inspection
fee.ThiswarrantyconstitutestheSeller’ssoleliabilityhereunderandisinlieuofanyotherwarrantyexpressed,
implied or statutory. Unless otherwise stated in writing, Seller makes no warranty that the goods depicted or
describedhereinaretforanyparticularpurpose.
Patent No. 424,953
7313 William Barry Blvd., North Syracuse, NY 13212
(Toll Free) 800-365-5525 (Phone) 315-233-5266 (Fax) 315-233-5276
www.icmcontrols.com
LIAF290-1
Press and release fault button to scroll through all saved faults.
Note: For initial setup, press and hold FAULT for 5 seconds to remove any previously stored faults.
Fault Problem Corrective Action
Back Phase Loss Not all three of the phases on the load side
are present
1. Re-energize the contactor.
2. If the fault reappears after the load energizes:
a. Turn all power OFF
b. Check all load side connections
c. Check the contacts of the contactor for debris or excess carbon.
Back Phase Rev Loads 1, 2, or 3 are not in sequence
(not 120º phase shifted)
1. Turn OFF all power.
2. Swap any 2 phases on the load side of the ICM450A and ICM450A PLUS+ only (example: swap load 1 and
load 2) *
3. Re-apply power.
Back Phase Unbalance A voltage unbalance between the three load
phases exceeds the unbalance setpoint
1. Press the READ button to observe the present load voltages. Check system for unbalance cause.
2. Increase the fault interrogation time if necessary.
3. Increase the percent unbalance setting if necessary.
Front Over Voltage Average phase-phase voltage exceeds the
maximum percentage
1. Check system for over-voltage cause.
2. Increase the percent over-voltage setting if necessary.
3. Increase the fault interrogation time if necessary.
Front Phase Loss Not all three of the phases on the line side
are present
1. Press and hold the READ button on the phase monitor or use an AC voltmeter to carefully measure all three
phase-phase line voltages (example: Line 1 Line 2, Line 2 Line 3, Line 3 Line 1).
2. Repair the missing phase.
Front Phase Reversal Lines 1, 2, or 3 are not in sequence
(not 120º phase shifted)
1. Turn OFF all power.
2. Swap any 2 phases on the line side of the ICM450A and ICM450A PLUS+ (example: swap Line 1 and Line
2)*
3. Re-apply power.
Front Phase Unbalance A voltage unbalance between the three line
phases exceeds the unbalance setpoint
1. Press the READ button to observe the present load voltages. Check system for unbalance cause.
2. Increase the fault interrogation time if necessary.
3. Increase the percent unbalance setting if necessary.
Front Under Voltage Average phase-phase voltage is below the
minimum percentage
1. Check system for under-voltage cause.
2. Increase the percent under-voltage setting if necessary.
3. Increase the fault interrogation time if necessary.
Fault Conditions
* Only swap phases during initial setup, not after the ICM450A and ICM450A PLUS+ has been in operation without errors.
