PARTS LIST
IC1 1110002751 S.IC TA75S01F(TE85R,F) T 32.5/8.8
IC2 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 42.9/24.7
IC3 1110007320 S.IC NJM2591V-TE1-#ZZZB B 45.8/38.9
IC51 1140015230 S.IC R4F20102NFA (EMPTY) B 77.7/38
IC52 1130015240 S.IC R1EX24016ATA00A B 85/25.2
IC53 1110007620 S.IC NJU7704F3-42A-TE1-#ZZZB B 87.6/44.6
IC54 1180003600 S.REG NJM2871BF05-TE1-#ZZZB T 15.6/34.8
IC55 1110007610 S.IC TPA0211DGNR B 13.3/42.1
IC56 1130011770 S.IC CD4066BPWR T 80.1/18.8
IC57 1110007550 S.IC R2A20178NP B 72.5/24.5
IC58 1110005340 S.IC NJM12902V-TE1-#ZZZB T 80.1/12
IC59 1110006350 S.IC LM2902PWR T 80.1/25.9
IC60 1110005340 S.IC NJM12902V-TE1-#ZZZB B 65.1/7.5
IC61 1140013200 S.IC CD4053BPWR T 80.1/38.3
IC62 1130011770 S.IC CD4066BPWR T 66.7/8.1
Q1 1560001700 S.FET RD07MUS2B-T112 B 28.6/13.5
Q2 1560001241 S.FET RD01MUS1-T113 B 36.3/14.4
Q3 1530003311 S.TRA 2SC5107-O(TE85R,F) B 42.2/13.1
Q6 1590004050 S.TRA LDTA144EET1G <SLVJ> T 33.3/5.9
Q8 1530003311 S.TRA 2SC5107-O(TE85R,F) T 54.8/18.5
Q9 1530003311 S.TRA 2SC5107-O(TE85R,F) B 55.9/18.5
Q10 1530003311 S.TRA 2SC5107-O(TE85R,F) T 60.7/18.5
Q11 1590004070 S.TRA LDTC144EET1G <SLVJ> B 54.9/23.8
Q12 1590004070 S.TRA LDTC144EET1G <SLVJ> B 64.3/23.9
Q13 1530002920 S.TRA 2SC4226-T1 R25 T 57.5/23.6
Q14 1530002920 S.TRA 2SC4226-T1 R25 T 60/23.6
Q15 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 64.1/18.7
Q17 1560000541 S.FET 2SK880-Y(T5RICOM,F) B 52.6/29.7
Q19 1590004070 S.TRA LDTC144EET1G <SLVJ> B 63.5/33.5
Q21 1560000841 S.FET 2SK1829(TE85R,F) B 28.4/30.5
Q22 1580000731 S.FET 3SK293(TE85L,F) B 25/27.8
Q23 1580000731 S.FET 3SK293(TE85L,F) B 36.4/27.3
Q24 1530003311 S.TRA 2SC5107-O(TE85R,F) B 38.3/42.6
Q25 1590004070 S.TRA LDTC144EET1G <SLVJ> T 49.3/35.1
Q26 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 39.6/30.1
Q27 1590004050 S.TRA LDTA144EET1G <SLVJ> B 56/36.4
Q51 1590001650 S.TRA XP4601(TX) T 65.5/42
Q52 1590004070 S.TRA LDTC144EET1G <SLVJ> T 75.4/31.4
Q58 1590003431 S.TRA UNR911HG0L B 54.9/7.1
Q59 1590004070 S.TRA LDTC144EET1G <SLVJ> B 49.1/7.3
Q63 1520000460 S.TRA 2SB1132 T100 R B 15.1/35.5
Q64 1590001190 S.TRA XP6501-(TX).AB B 19.3/36
Q71 1510001090 S.TRA KTA2015Y-RTK/P B 65.1/36.6
Q72 1510000771 S.TRA 2SA1586-GR(TE85L,F) B 65.6/31.1
Q73 1510001090 S.TRA KTA2015Y-RTK/P B 78.6/23.8
Q74 1520000460 S.TRA 2SB1132 T100 R B 5.3/34.4
Q75 1590001190 S.TRA XP6501-(TX).AB T 4.5/35.2
Q76 1590004070 S.TRA LDTC144EET1G <SLVJ> T 6.8/35.2
Q81 1590003271 S.TRA UNR9210G0L B 70.5/45.8
Q82 1590004050 S.TRA LDTA144EET1G <SLVJ> T 71.6/39.5
Q83 1590004050 S.TRA LDTA144EET1G <SLVJ> T 71.6/41.6
Q84 1590004070 S.TRA LDTC144EET1G <SLVJ> B 19.2/43.8
Q85 1590004070 S.TRA LDTC144EET1G <SLVJ> T 21.1/31.8
D1 1750001910 S.DIO HVD144AKRF-E B 16.2/16.3
D2 1790001790 S.DIO RB876W TL B 14.5/13.8
D3 1790001790 S.DIO RB876W TL B 19.4/9.1
D5 1750001890 S.DIO HVD142AKRF-E B 49.6/15.2
D6 1750001890 S.DIO HVD142AKRF-E B 49.6/16.6
D11 1750001880 S.VAR HVL375CKRF-E T 57.4/29.2
D12 1750001550 S.VAR HVD376BKRF-E T 54.1/25.6
D13 1750001550 S.VAR HVD376BKRF-E T 55.1/25.6
D14 1750001880 S.VAR HVL375CKRF-E T 59.3/27.2
D15 1750001570 S.VAR HVL355CMKRF-E T 59.3/29.2
D16 1750001550 S.VAR HVD376BKRF-E T 63.8/25.1
D17 1750001550 S.VAR HVD376BKRF-E T 62.8/23.2
D18 1750001810 S.DIO L1SS400T1G <SLVJ> T 46.3/32.6
D21 1750001810 S.DIO L1SS400T1G <SLVJ> B 30.9/33.2
D22 1750001910 S.DIO HVD144AKRF-E B 16.2/20.5
D23 1750001910 S.DIO HVD144AKRF-E B 14.1/23.3
D24 1750001880 S.VAR HVL375CKRF-E B 17.4/27.7
D26 1750001880 S.VAR HVL375CKRF-E B 18.4/27.7
D28 1750001780 S.VAR HVB350BYPTL-E B 31/27.8
D31 1750001790 S.DIO 1SS390 TE61 B 54.1/39.8
D32 1750001790 S.DIO 1SS390 TE61 B 51.7/36.8
D33 1750001790 S.DIO 1SS390 TE61 B 56.7/39.8
D34 1750001790 S.DIO 1SS390 TE61 B 58.1/38.5
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
D35 1790001241 S.DIO MA2S7280GL [USA-11] T 37.5/6.3
1790001241 S.DIO MA2S7280GL [USA-12]
1790001241 S.DIO MA2S7280GL [USA-13]
1790001241 S.DIO MA2S7280GL [EXP-11]
1790001241 S.DIO MA2S7280GL [EXP-12]
1790001241 S.DIO MA2S7280GL [EXP-13]
1790001241 S.DIO MA2S7280GL [EXP-21]
1790001241 S.DIO MA2S7280GL [EXP-22]
1790001241 S.DIO MA2S7280GL [EXP-23]
1790001241 S.DIO MA2S7280GL [EXP-01]
1790001241 S.DIO MA2S7280GL [EXP-03]
1790001241 S.DIO MA2S7280GL [EXP-31]
1790001241 S.DIO MA2S7280GL [CHN-31]
1790001241 S.DIO MA2S7280GL [AUS-21]
1790001241 S.DIO MA2S7280GL [AUS-22]
1790001241 S.DIO MA2S7280GL [AUS-23]
1790001241 S.DIO MA2S7280GL [RUS-21]
1790001241 S.DIO MA2S7280GL [RUS-22]
1790001241 S.DIO MA2S7280GL [RUS-23]
D51 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 67.9/45.8
D52 1750001790 S.DIO 1SS390 TE61 B 87/33.7
D53 1750001810 S.DIO L1SS400T1G <SLVJ> B 69.1/3.1
D55 1750001810 S.DIO L1SS400T1G <SLVJ> B 21.9/33.8
FI1 2030000870 S.MON MFT46.3P3 46.350 MHz (FL-442) B 36.2/34.6
FI2 2020002410 CER LTM450FW <JJE>
FI3 2020002570 CER LTM450HW <JJE>
X1 6070000310 S.DIS JTBM450CX70 <JJE> T 47.6/40.9
X2 6050012050 S.XTA CR-794 TTS14VSB-A6 15.3 MHz T 41.9/15
X51 6050012730 S.XTA CR-864 (SMD-49/12.288 MHz)
<JJE> T 86.9/38.5
L1 6200012780 S.COI 0.30-1.4-6TL 27.2N <COMO> B 9.4/7.9
L2 6200012470 S.COI 0.30-1.7-7TL 45.3N <COMO> B 9.6/11.7
L3 6200012910 S.COI 0.35-1.6-8TL 45.5N <COMO> B 11.2/15.6
L4 6200002861 S.COI NLV25T-4R7J B 18.4/17.8
L5 6200012470 S.COI 0.30-1.7-7TL 45.3N <COMO> B 18.4/14.1
L6 6200012390 S.COI 0.30-0.92-3TR 5.8N <COMO> B 22/14.1
L7 6200013010 S.COI 0.30-0.9-5TL 10.3N <COMO> B 24.3/15.3
L8 6200013100 S.COI 0.45-1.5-5TL 18.3N <COMO> B 25.2/19
L9 6200007871 S.COI ELJRF 39NJFB B 42.2/11.3
L11 6200012470 S.COI 0.30-1.7-7TL 45.3N <COMO> B 14.1/19.6
L12 6200011021 S.COI ELJRF 82NJFB B 12.4/23.1
L13 6200008090 S.COI LQW2BHN68NJ03L B 14.9/26.8
L14 6200008090 S.COI LQW2BHN68NJ03L B 20.9/26.8
L15 6200010910 S.COI LQW18AN56NG00D B 27.1/27.8
L16 6200010910 S.COI LQW18AN56NG00D B 33.3/27.8
L18 6200007901 S.COI ELJRF 22NJFB B 32.8/13.4
L19 6200011011 S.COI ELJRF 68NJFB B 34.4/25.1
L20 6200004770 S.COI ELJNC R56J-F B 39.4/27.7
L23 6200012170 S.COI MLG1608SR18J-T T 39.4/34.6
L24 6200012170 S.COI MLG1608SR18J-T T 41.5/31.8
L31 6200011031 S.COI ELJRF R10JFB T 56.6/17.7
L32 6200011031 S.COI ELJRF R10JFB B 56.5/20.4
L33 6200011031 S.COI ELJRF R10JFB T 62.5/17.7
L34 6200007170 S.COI MLF1608A 3R3K-T B 57.4/29.2
L35 6200008090 S.COI LQW2BHN68NJ03L T 55.7/27.7
L36 6200003640 S.COI MLF1608E 100K-T T 53/25.6
L37 6200007720 S.COI LQW2BHN33NJ03L T 53.8/22.6
L38 6200007170 S.COI MLF1608A 3R3K-T B 50.6/25.7
L39 6200007170 S.COI MLF1608A 3R3K-T B 59.1/28.5
L40 6200007760 S.COI LQW2BHN82NJ03L T 62.9/27.9
L41 6200003640 S.COI MLF1608E 100K-T T 64.6/27.5
L42 6200008090 S.COI LQW2BHN68NJ03L T 64.3/20.6
L43 6200007170 S.COI MLF1608A 3R3K-T B 60/22.7
L46 6200007881 S.COI ELJRF 33NJFB B 48.2/19.3
R1 7030005070 S.RES ERJ2GEJ 683 X (68K) B 9.1/5.7
R2 7030008280 S.RES ERJ2GEJ 271 X (270) B 20.6/19.2
R3 7030008280 S.RES ERJ2GEJ 271 X (270) B 20.6/18.3
R4 7030005050 S.RES ERJ2GEJ 103 X (10K) B 14.5/15.4
R5 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 15.3/12.2
R6 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 19.4/10.8
R7 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 17.9/7.9
R8 7030005050 S.RES ERJ2GEJ 103 X (10K) T 30.8/5.9
R9 7030005050 S.RES ERJ2GEJ 103 X (10K) T 31.7/5.9
R10 7030005070 S.RES ERJ2GEJ 683 X (68K) T 32.6/11.3
R11 7030005310 S.RES ERJ2GEJ 124 X (120K) T 31.7/11.3
R12 7030005110 S.RES ERJ2GEJ 224 X (220K) T 35.7/5.9
R13 7030005530 S.RES ERJ2GEJ 100 X (10) T 35.7/9.6
R14 7030004980 S.RES ERJ2GEJ 101 X (100) T 34.8/7.6
R15 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 35.7/7.6
R16 7030010040 S.RES ERJ2GEJ-JPW T 29.4/7.1
R21 7030007250 S.RES ERJ2GEJ 220 X (22) B 32.3/10.9
R22 7030005090 S.RES ERJ2GEJ 104 X (100K) B 33.2/9.2
R23 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 34.1/9.2
R24 7030005590 S.RES ERJ2GEJ 680 X (68) B 38.4/10.9
R25 7030005060 S.RES ERJ2GEJ 333 X (33K) B 39.3/9.2
R26 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 38.4/9.2
R31 7030005530 S.RES ERJ2GEJ 100 X (10) B 42.2/14.9
R32 7030005120 S.RES ERJ2GEJ 102 X (1K) B 44/14.9
R33 7030004980 S.RES ERJ2GEJ 101 X (100) B 44.6/13.1
R35 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 46.4/14
