Icom IC-F3061T Servise Manual

7 - 11
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-A UNIT] (for F3160 series)
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
EP1 6910015370 S.BEA ACZ1005Y-102-T B 53.5/22.5
EP3 6910015370 S.BEA ACZ1005Y-102-T B 45.5/36.8
EP4 6910015600 S.BEA ACZ1005Y-241 (240) B 56.4/39.6
EP5 6910015370 S.BEA ACZ1005Y-102-T B 62.6/21.7
EP7 0880002600 UBD EX-2887
[F3062S EUR-01], [F3160DT/DS]
S.=Surface mount
[RF UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC601 1110002750 S.IC TA75S01F (TE85R)
Except [FRG-01] T 24.4/23.1
1110002751 S.IC TA75S01F (TE85R,F) [FRG-01] T 24.4/23.1
Q601 1560001230 S.FET RD07MVS1
[F3061T], [F3063T], [F3061S], [F3063S] B 8/6.5
1560001231 S.FET RD07MVS1-T112
[F3062T], [F3062S EUR-01], [FRG-01] B 8/6.5
Q602 1560001241 S.FET RD01MUS1-T113 B 3.5/13.2
Q603 1530003420 S.TR 2SC5110-O (TE85R)
[F3061T], [F3063T], [F3061S], [F3063S] B 8/18.1
1530003421 S.TR 2SC5110-O (TE85R,F)
[F3062T], [F3062S EUR-01], [FRG-01] B 8/18.1
Q604 1590002160 S.TR XP6401-(TX) T 7.7/15.3
Q605 1530002060 S.TR 2SC4081 T106 R T 8/17.9
Q606 1590003290 S.TR UNR9213J-(TX) T 21/20.5
D601 1750000580 S.DIO 1SV307 (TPH3)
[F3061T], [F3063T], [F3061S], [F3063S] T 22.4/10
1750000581 S.DIO 1SV307 (TPH3,F)
[F3062T], [F3062S EUR-01], [FRG-01] T 22.4/10
D603 1750000580 S.DIO 1SV307 (TPH3)
[F3061T], [F3063T], [F3061S], [F3063S] B 17.8/13.2
1750000581 S.DIO 1SV307 (TPH3,F)
[F3062T], [F3062S EUR-01], [FRG-01] B 17.8/13.2
D604 1790001670 S.DIO RB706F-40T106 T 17.4/6.1
D605 1790001670 S.DIO RB706F-40T106 B 28.4/21.7
D606 1790001250 S.DIO MA2S111-(TX) T 29.8/21.7
D607 1730002430 S.ZEN MA8150-M (TX)
[F3062T], [F3060S] T 17.2/21.4
L601 6200008580 S.COL 0.30-1.4-6TL 32N
Except [FRG-01] B 30.8/9.2
6200012780 S.COL 0.30-1.4-6TL 27.2N [FRG-01] B 30.8/9.2
L602 6200008280 S.COL 0.30-1.7-7TL 50N
Except [FRG-01] B 30.2/12.4
L602 6200012470 S.COL 0.30-1.7-7TL 45.3N [FRG-01] B 30.2/12.4
L603 6200008170 S.COL 0.35-1.6-8TL 54N
Except [FRG-01] B 27.3/15.7
6200012910 S.COL 0.35-1.6-8TL 45.5N [FRG-01] B 27.3/15.7
L604 6200008280 S.COL 0.30-1.7-7TL 50N
Except [FRG-01] B 20.1/13.1
6200012470 S.COL 0.30-1.7-7TL 45.3N [FRG-01] B 20.1/13.1
L605 6200002861 S.COL NLV25T-4R7J T 25.2/11.1
L606 6200008580 S.COL 0.30-1.4-6TL 32N
Except [FRG-01] B 20.5/4.4
6200012780 S.COL 0.30-1.4-6TL 27.2N [FRG-01] B 20.5/4.4
L607 6200008490 S.COL 0.30-0.9-3TR 7.5N
Except [FRG-01] B 16/4.1
6200012390 S.COL 0.30-0.92-3TR 5.8N [FRG-01] B 16/4.1
L608 6200009710 S.COL 0.30-0.9-4TL 10.5N
Except [FRG-01] B 12.6/5.6
6200012400 S.COL 0.30-0.91-4TL 8.6N [FRG-01] B 12.6/5.6
L609 6200008330 S.COL 0.45-1.4-4TL 15N
Except [FRG-01] B 9.2/11.8
6200012960 S.COL 0.45-1.4-4TL 12.1N [FRG-01] B 9.2/11.8
L610 6200005711 S.COL ELJRE 27NGFA B 6.7/13.8
L611 6200003590 S.COL EXCCL3225U1 B 14.6/17.4
L612 6200005731 S.COL ELJRE 39NGFA B 4.6/18.6
L613 6200006190 S.COL BLM21PG300SN1D T 13.1/20.2
R601 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 29/8.3
R603 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 18/3.3
R604 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 17.7/9
R605 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 17.7/10
R606 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 27.6/20.4
R607 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 19.4/20.9
R608 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 26.6/22
R609 7030005530 S.RES ERJ2GEJ 100 X (10) B 24.1/24.7
R610 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 28.6/22
R611 7030004990 S.RES ERJ2GEJ 221 X (220) T 29.4/20
R613 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 4.2/7.4
R614 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 2.4/8.6
R615 7030007250 S.RES ERJ2GEJ 220 X (22) B 4/8.6
R616 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 3.4/17.4
R617 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 2.4/18.4
R618 7030004980 S.RES ERJ2GEJ 101 X (100) B 3.8/16.2
R619 7030004980 S.RES ERJ2GEJ 101 X (100) B 6/17.7
R620 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 7.7/21.2
R621 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 6.7/20
R622 7030005530 S.RES ERJ2GEJ 100 X (10) T 6.8/21.4
R623 7030007330 S.RES ERJ1WRSJR15U (0.15) T 16/16.8
R624 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 12.9/14.4
R625 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 6/18.1
R626 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 7.7/20.2
R627 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 6.7/20.2
R628 7030003370 S.RES ERJ3GEYJ 271 V (270) T 26.7/17
R629 7030003370 S.RES ERJ3GEYJ 271 V (270) T 25.4/17
R631 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 21.7/18.7
R632 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) B 28.7/19.2
R633 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
[F3061T], [F3063T] B 26.5/20.8
7030007340 S.RES ERJ2GEJ 153 X (15 k)
[F3062T], [F3060S] B 26.5/20.8
C601 4030006990 S.CER C1608 CH 1H 080D-T B 30.6/6.4
C602 4030011770 S.CER C1608 CH 1H 060B-T B 33.1/10.5
C604 4030009650 S.CER C1608 CH 1H 240J-T B 28.5/7.7
C605 4030009920 S.CER C1608 CH 1H 050B-T B 32.3/13.1
