Icom IC-F3061T Servise Manual

7 - 12
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[RF UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C606 4030007060 S.CER C1608 CH 1H 270J-T B 28.1/11.7
C608 4030009540 S.CER C1608 CH 1H 1R5B-T B 27.7/17.8
C609 4030007020 S.CER C1608 CH 1H 120J-T B 25.5/11.7
C610 4030017460 S.CER ECJ0EB1E102K B 24.1/12.1
C611 4030007020 S.CER C1608 CH 1H 120J-T B 23.4/10.3
C612 4030017650 S.CER ECJ0EC1H270J B 21.1/15.5
C613 4030017460 S.CER ECJ0EB1E102K T 25.8/13.3
C614 4030017460 S.CER ECJ0EB1E102K T 25.3/19.2
C615 4030017460 S.CER ECJ0EB1E102K T 21/7.8
C616 4030007040 S.CER C1608 CH 1H 180J-T B 20.9/8
C617 4030007040 S.CER C1608 CH 1H 180J-T B 19.6/8
C618 4030017530 S.CER ECJ0EC1H0R5B T 17.4/3.8
C619 4030017460 S.CER ECJ0EB1E102K T 17.7/8
C620 4030017460 S.CER ECJ0EB1E102K B 19.3/6.3
C622 4030011770 S.CER C1608 CH 1H 060B-T B 18.3/8
C623 4030007100 S.CER C1608 CH 1H 560J-T B 17.9/5.4
C624 4030007110 S.CER C1608 CH 1H 680J-T B 14.5/6.5
C626 4030017460 S.CER ECJ0EB1E102K T 28.2/17.5
C627 4030016790 S.CER ECJ0EB1C103K T 21.8/22.3
C628 4030016790 S.CER ECJ0EB1C103K T 27.6/22
4030016930 S.CER ECJ0EB1A104K
[F3061T], [F3063T], [F3061S], [F3063S] T 27.6/22
4030016940 S.CER ECJ0EB1A393K
[F3062T], [F3062S EUR-01], [FRG-01] T 27.6/22
C629 4030017460 S.CER ECJ0EB1E102K B 25.8/18.8
C630 4030016930 S.CER ECJ0EB1A104K T 24.5/25.3
C631 4030017460 S.CER ECJ0EB1E102K T 28.6/18.7
C632 4030017460 S.CER ECJ0EB1E102K B 21/20.2
C633 4030017460 S.CER ECJ0EB1E102K B 13.7/15.4
C634 4030017460 S.CER ECJ0EB1E102K B 2.2/7.4
C635 4030017730 S.CER ECJ0EB1E471K B 3.2/7.4
C637 4030017460 S.CER ECJ0EB1E102K T 3.1/9.3
C638 4030017430 S.CER ECJ0EC1H101J B 4.7/9.8
C639 4030017490 S.CER C1608 JB 1A 105K-T B 13.8/14.2
C640 4030017460 S.CER ECJ0EB1E102K B 8.1/14.7
C642 4030016790 S.CER ECJ0EB1C103K B 2.2/16.2
C643 4030017460 S.CER ECJ0EB1E102K B 2.2/17.2
C644 4030017420 S.CER ECJ0EC1H470J T 2/18.8
C645 4030017460 S.CER ECJ0EB1E102K T 4.2/18.8
C646 4030017430 S.CER ECJ0EC1H101J B 5/16.5
C647 4030017420 S.CER ECJ0EC1H470J T 5.6/21.5
C648 4030017460 S.CER ECJ0EB1E102K B 5.7/21.5
C649 4030017460 S.CER ECJ0EB1E102K T 10.1/22.8
C650 4030017460 S.CER ECJ0EB1E102K B 6/18.7
C651 4030017650 S.CER ECJ0EC1H270J B 8.3/20
C653 4030017460 S.CER ECJ0EB1E102K T 17.2/14.2
C654 4030017460 S.CER ECJ0EB1E102K T 6/17.1
C655 4030017460 S.CER ECJ0EB1E102K T 8.7/20.2
C656 4030016930 S.CER ECJ0EB1A104K T 16.5/19.4
C657 4030017460 S.CER ECJ0EB1E102K T 15.5/19.4
C658 4030017420 S.CER ECJ0EC1H470J T 14.5/19.4
C659 4030017420 S.CER ECJ0EC1H470J T 14.7/21.2
C660 4030017460 S.CER ECJ0EB1E102K T 13.2/23.8
C661 4030016930 S.CER ECJ0EB1A104K T 12.2/23.8
C662 4030017460 S.CER ECJ0EB1E102K B 6.8/11.2
C663 4030009920 S.CER C1608 CH 1H 050B-T B 34.3/10.5
C664 4030011770 S.CER C1608 CH 1H 060B-T B 15.7/6.5
C665 4030017530 S.CER ECJ0EC1H0R5B B 29.8/20.1
C666 4030017460 S.CER ECJ0EB1E102K B 26.5/22.4
C667 4030018910 S.CER C1608 JB 0J 475K-T
[F3062T], [F3062S EUR-01], [FRG-01] only B 23.5/22.3
J601 6910017940 CNR IMSA-9230B-1-05Z118-PT1
J602 6910017940 CNR IMSA-9230B-1-05Z118-PT1
F601 5210000970 S.FUS ERBSE3R00U T 13.9/22.4
EP602 6910012350 S.BEA MMZ1608Y 102BT B 7.8/15.8
S.=Surface mount
[JACK UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
D801 1790001810 S.VSR AVR-M1005C080MTABB B 13.7/1.7
D802 1790001810 S.VSR AVR-M1005C080MTABB B 14.7/3.8
D803 1790001810 S.VSR AVR-M1005C080MTABB B 13.8/3.8
D804 1790001810 S.VSR AVR-M1005C080MTABB B 14.1/2.6
D805 1790001810 S.VSR AVR-M1005C080MTABB B 13.5/0.8
J801 6510025140 S.CNR 10FLT-SM1-TB Except [FRG-01] B 5/2.6
6510025141 S.CNR 10FLT-SM2-TB (LF) [FRG-01] B 5/2.6
EP801 6910012350 S.BEA MMZ1608Y 102BT B 10/3.7
EP802 6910012350 S.BEA MMZ1608Y 102BT B 10/2.2
EP803 6910012350 S.BEA MMZ1608Y 102BT B 10/.9
[VR UNIT] (for other than [FRG-01])
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
Q701 1590001400 S.TR XP1214 (TX) T 32.2/6.2
R701 7410001140 S.ARY EXB28V104JX T 11.4/1.8
R702 7030007280 S.RES ERJ2GEJ 331 X (330) T 31.7/8.6
R703 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 32.7/8.6
R704 7210003061 VAR TP76N00N-15F-A103-2251A
R705 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.2/2.8
C701 4030017420 S.CER ECJ0EC1H470J T 10.1/5.2
C702 4030017420 S.CER ECJ0EC1H470J T 11.1/5.2
C703 4030017420 S.CER ECJ0EC1H470J T 12.1/5.2
C704 4030017420 S.CER ECJ0EC1H470J T 14.3/3.2
J701 6510024930 S.CNR 20RF-JMCSG1BTF (N) (LF)(SN) B 11.4/4.1
DS701 5040002670 S.LED CL-165HR/YG T 33.5/11.1
S701 2250000490 ECR TP70TF5163-15.9F-2775
S702 2230001060 S.SW EVQ-PUL 02K T 8/10.4
[VR-A UNIT] (for [FRG-01])
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
Q701 1590001400 S.TR XP1214 (TX) T 32.2/6.2
R701 7410001140 S.ARY EXB28V104JX T 11.2/1.8
R702 7030007280 S.RES ERJ2GEJ 331 X (330) T 31.7/8.6
R703 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 32.7/8.6
R704 7210003061 VAR TP76N00N-15F-A103-2251A
R705 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.1/2.9
C701 4030017420 S.CER ECJ0EC1H470J T 10.1/5.2
C702 4030017420 S.CER ECJ0EC1H470J T 11.1/5.2
C703 4030017420 S.CER ECJ0EC1H470J T 12.1/5.2
C704 4030017420 S.CER ECJ0EC1H470J T 14/3.9
J701 6510024930 S.CNR 20RF-JMCSG1BTF (N) (LF)(SN) B 11.4/4.1
DS701 5040002670 S.LED CL-165HR/YG T 33.5/11.1
S701 2250000600 ECR TP70N1035E20-15.9F-2893
S702 2230001060 S.SW EVQ-PUL 02K T 8/10.4
