2141 ICON Way, Vacaville, CA 95688 ‐ Tel: 707.564.4000 – www.iconaircraft.com
SERVICE LETTER
SL-042820 REV A
ICA009717-E PAGE 7 of 9
**NOTE**
Mix the cartridges of AC-251 adhesive one by one as they are needed. Do not mix all the adhesive at
once.
3. Apply a 1/8” to 1/4” Diameter continuous bead of adhesive approximately centered along
indicated (highlighted in red) curve. Repeat process for LH side.
Figure 4 Sealant Application to Seawing
4. Place RH seawing tip onto 4x Studs (previously installed) on the fuselage. Repeat for LH Side.
