ICON WEIDER PRO 4500 - Page 24

M6 Washer (82)
M8 Nylon
Locknut (58)
M8 Washer (59)
M10 Nylon Locknut (56)
M10 x 40mm Button Bolt (77)
M8 x 19mm
Shoulder
Bolt (65)
M6 x 80mm Button Screw (70)
M4 x 19mm
Screw (69)
M8 x 74mm Carriage Bolt (78)
M6 x 17mm
Buton Screw (62)
M10 x 45mm Button Bolt (81)
M10 x 52mm Button Bolt (66)
M10 x 62mm Button Bolt (75)
M8 x 77mm Button Bolt (68)
M10 x 78mm Button Bolt (71)
M10 x 72mm Button Bolt (85)
M10 x 80mm Button Bolt (79)
M10 x 90mm Button Bolt (67)
M10 x 155mm Button Bolt (74)
M4 x 10mm
Screw (84)
M
M10 Washer (57)
M10 Large Washer (80)
M10 x 70mm Bolt Set (73)
M12 Nut (86)
Large Washer (87)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
