TABLE # 3.2
Technical specifications, LBO125DABR13-B (BECKETT, RIELLO AND AERO BURNER)
TABLE # 4.2
Air delevery - CFM with air filter
Firing rate USGPH 0.75 0.85 1.00 1.10
Input (BTU/h) 105 000 119 000 140 000 154 000
Heating capacity (BTU/h) 84 525 95 795 112 700 123 970
Maximum heating temperature rise (degr.F)
BURNER BECKETT (3450 RPM)
Low firing rate baffle
Static disc, model
Nozzle - 100 PSIG pump pressure (Delavan) 0.75 - 70W 0.85 - 70W 1.00 -70W 1.10 - 70W
Combustion air adjustment (band / shutter) 1 / 1 1 / 4 2 / 2 3 / 3
RIELLO BURNER; MODEL 40
Nozzle (Delavan) 0.60 - 60W 0.75 - 60W 0.85 - 60W 0.85 - 60W
Pump pressure (PSIG) 155 130 140 170
Combustion air adjustment (turbulator / damper) 2 / 3.25 2.5 / 4 2 / 2.5 3 / 2.5
AERO BURNER (1725 RPM)
Nozzle - 100 PSIG pump pressure (Delavan) 0.75 - 70W 0.85 - 70W 1.00 - 70W 1.10 - 70W
Volts - Hertz - Phase
Operating voltage range
Rated current (Amp.)
Minimum ampacity for wiring sizing
Max. fuse size (Amps)
Blower speed at 0.4" W.C. static pressure MED-LO MED-HI HIGH N / A
Blower speed at 0.2" W.C. static pressure MED-LO MED-HI HIGH HIGH
Motor (HP) / number of speeds
Blower wheel size (in.)
Filter quantity and size
F5 (Tube insertion 5 1/4")
2 3/4 #3383
F3 (Tube insertion 5 1/4")
(2) 15 X 20
115 - 60 - 1
104 - 132
11.4
12.8
15
1/3 HP / 4 speeds
10 X 10
FAFC-2 (TUBE INSERTION 5 3/8")
55 - 85 Degr.F
AFG-F3 (TUBE INSERTION 5 3/16")
YES
ELECTRICAL SYSTEM
BLOWER DATA
RATING AND PERFORMANCE
0.2 0.4
MED-LO
1175 1000
MED-HI
1250 1200
HIGH
1375 1300
LBO125DABR13-B
EXTERNAL STATIC PRESSURE WITH AIR FILTER
SPEED
