5
The required minimum clearances for this furnace are specified
in table #1.
The furnace should be located as close as possible to the chimney to
keep vent connections short and direct. The furnace should also be
located as near as possible to the center of the air distribution system.
CAUTION
Do NOT operate furnace in a corrosive atmosphere
containing chlorine, fluorine or any other damaging
chemicals. Refer to Part 1, section 5.2.
WARNINGWARNING
Electrical shock hazard.
This furnace is not watertight and is not designed
for outdoor installation. This furnace shall be
installed in such a manner as to protect the
electrical components from water.
Outdoor installation would lead to a hazardous
electrical condition and to premature furnace
failure, property damage, bodily injury or death.
TABLE #1
Minimum clearances – combustion materials (in)
LOCATION APPLICATION In
Furnace 1”
Sides
Supply plenum within 6 ft of furnace 1”
Back Furnace 18”
Furnace or plenum 1”
Top
Horizontal warm air duct within 6 ft of furnace 1”
Bottom Furnace (combustible floor) 0”
Horizontally or below flue pipe 9”
Flue pipe
Vertically above flue pipe 9”
Front From burner 24”
4) VENTING
WARNINGWARNING
Poison carbon monoxide gas, fire and explosion
hazard.
Read and follow all instructions in this section.
Failure to properly vent this furnace can result in
property damage, personal injury and/or death.
CAUTION
When the furnace (chimney installation) is co-vented
with other combustion appliances such as a water
heater, the allowable venting materials (i.e. L-Vent etc.)
for use with those appliances should also be
investigated.
The oil furnaces are certified for use with L-vent, A-vent, tile-lined and
metal-liner-tile-lined chimneys. The appliance may be installed in a
chimney of the proper size and adequate chimney base temperature
as specified in the Installation Code. The relevant excerpt from the
code is found in this section - Use it as a guide when local or national
codes do not exist.
Flue pipe sizing:
The following table is an except from the installation code and
indicates permitted flue sizes and minimum base temperatures for
circular flues in chimney with thermal resistance less than R6 (6 ft
2
•hr
•°F / Btu). Where a new appliance, burner, or chimney is installed,
chimney vent sizes and maximum flue-gas temperatures (measured at
the chimney connector with the barometric damper shut, after 5
minutes of operation) shall comply with the table #2.
WARNINGWARNING
Poison carbon monoxide gas hazard
Never install a hand operated damper in the vent
pipe. However, any Underwriters Laboratories
listed electrically operated automatic type vent
damper may be installed if desired. Be sure to
follow instructions provided with vent damper.
Read and follow all instructions in this section.
Failure to properly vent this furnace or other
appliances can result in property damage, personal
injury and/or death.
NOTES: Thermal resistance values for typical chimneys are as
follows:
R2 (2 ft
2
•hr •°F / Btu): clay-lined masonry, A-vent
R3 (3 ft
2
•hr •°F / Btu): metal liner in clay-lined
Masonry
R6 (6 ft
2
•hr •°F / Btu): metal or clay-lined masonry
with R4.5 (4.5 ft
2
•hr •°F / Btu)
insulation between liner and
masonry (e.g. 2 in. of
expanded mica or 1 3/8 in. of
high density glass fibreboard.)
