TECHNICAL SUPPORT MANUAL Split System Heat Pump: (C,H,T)4H3
428 04 5402 00 5
MULTIPLYING FACTORS
(Refer to pages 5−11)
† Total capacities are net (I.D. blower heat subtracted) system capacities based on 25 foot (7.6m) line set.
If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
†† At TVA rating indoor condition (75 °F db, 63 °F wb), all other indoor air temperatures are at 80 ° F db
If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
* System amps are total of indoor and outdoor amps.
‡ Chart data is for 80° F indoor dry bulb. For indoor db temperatures other than 80° F, measure Indoor db and Indoor CFM, and plug these into the
formula below. Measure outdoor db and indoor wet bulb, apply these to the chart above, find MBh and S/T, and plug these into the formula below.
(Note: if indoor db is the only thing changing, total capacity, MBh, stays the same.)
Sensible Capacity at Indoor db LOWER than 80 ° F = ( MBh x S/T ) −
( 80 − Indoor db ) x 835 x Indoor CFM
1000
(
)
Sensible Capacity at Indoor db HIGHER than 80 ° F = ( MBh x S/T ) +
( Indoor db − 80 ) x 835 x Indoor CFM
1000
(
)
