This document provides troubleshooting information for Merit flat saws, designed to assist users in diagnosing and resolving common operational issues. It covers a range of problems related to the saw's hydraulic system, engine, cooling, and starting mechanisms.

Function Description:

The Merit flat saw is a robust piece of equipment used for cutting concrete and other hard surfaces. Its primary function is to provide precise and efficient cutting for various construction and demolition tasks. The saw incorporates a hydraulic system for raising and lowering the blade, an engine for power, and a cooling system to maintain optimal operating temperatures. The troubleshooting guide is intended to help users maintain the saw's functionality and address common malfunctions that may arise during operation.

Important Technical Specifications (Derived from Troubleshooting Context):

Hydraulic System: The saw utilizes a hydraulic system for blade lift and control. Key components include a lift pump, pressure relief setting, solenoid, and a reservoir that holds 1 quart of ATF (Automatic Transmission Fluid). The system operates under pressure, and proper oil levels and leak-free connections are critical for its function.
Electrical System: A 12V power supply is essential for various electrical components, including the lift pump solenoid, engine starter, and cooling fan. The system includes a 40A fuse in the wire harness for the cooling fan, battery posts, and connections that need to be tight and free of corrosion.
Engine and Cooling System: The saw is equipped with an engine that requires a cooling system to prevent overheating. This system includes a cooling fan, a temperature sensor (triggering at 180 degrees F), and a relay. The engine also has an ignition switch, an ECU (Engine Control Unit), a fuel pump, and a fuel filter.
Mechanical Components: The saw features mechanical elements such as a differential, a positraction system, and a right-angle drive shaft. Belts are used in the mechanical fan system, and their tension is adjustable via a blue tensioner.

Usage Features:

Blade Control: The saw's blade can be raised and lowered using a hydraulic system. Users can adjust the pump pressure via a pressure relief setting on the pump manifold for fine-tuning blade control.
Safety Features: An emergency stop mechanism is integrated into the saw, which can be disengaged by pulling and twisting. When working with a raised hydraulic system, it is crucial to support the weight of the saw to ensure safety.
Positraction System: The positraction system can be engaged or disengaged using a cable. The differential cable should be pulled into neutral and twisted to lock the lever in position. To disengage, the "Pull" cable needs to be pushed down.
Engine Start: The saw starts via an ignition switch, and the fuel pump has an audible sound when the key is turned to the "on" position.
Troubleshooting Guidance: The manual provides clear "How to" steps for each troubleshooting solution, guiding users through adjustments, inspections, and part replacements. For instance, it details how to adjust pump pressure, check electrical connections, and inspect mechanical components.

Maintenance Features:

Hydraulic System Maintenance: Regular checks of hydraulic oil level in the reservoir and inspection for leaks in fittings and hoses are essential. The reservoir holds 1 quart of ATF.
Electrical System Maintenance: Users should regularly inspect battery posts and connections for tightness and corrosion. The 40A fuse in the cooling fan's wire harness should be visually inspected.
Engine and Fuel System Maintenance: The fuel tank should be visually inspected for fuel levels (not relying solely on a gauge). The fuel filter needs to be inspected and replaced if clogged or dirty. The engine's ECU connections and ignition switch should be checked for continuity and corrosion.
Cooling System Maintenance: The cooling fan and fan blades should be kept clear. The tension of the fan belt can be adjusted using a blue tensioner.
Mechanical System Maintenance: Belts should be checked for looseness or breakage. The positraction system's shift fork spring may require lubrication with oil or WD-40 to ensure proper release.
Part Replacement: The guide frequently refers to replacing specific parts such as the lift pump, solenoid, relay, belts, right-angle drive box, fan, and various valves. Users are directed to "See parts manual for required parts" or "See technical sheets" for detailed instructions on these replacements.
Professional Support: For complex issues, such as a faulty lift pump, ECU problems, or electrical starter issues, the guide recommends calling service for support or having the component electrically inspected.
Documentation Reference: The document emphasizes referring to the specific Owner's Manual for the saw and checking the ID Plate for model identification. It also suggests reviewing "Raise/Lower instruction sheet" and "technical sheets" for detailed procedures.
