ICS Nav6 Manual

ICS
29/01/2019 man03034 nav6 display upgrade procedure.docx Issue 3 2
Programming Cable wiring for NAV6 displays with software earlier than Version 1.5 using the ‘fin’ style active
antenna or a NAV6A receiver (white box)
ICS.6020.32 - NAV6 USB to Serial Adaptor (Optional)
NAV6 Printer
GPS
SENSOR
+
-
BLACK RED
POWER
SOURCE
PLT02410 V4 NAVTEX RECEIVER
SERIAL NO.
ELECTRO NICS
ICS
White (with black sleeve)
Black
Green
White
Blue
Red
(Part no: ICS.6020.31)
Black
+V
Prog
Tx
Rx
GND
(Part no: ICS.6020.20)
Green
If you have an old-style NAV6 Programming Lead (ICS Part
No: 6020.20), refer to the wire colours in this table
Red
Brown
"New" Prog Lead Colour Signal"Old" Prog Lead Colour
OR
ICS.6020.31 - NAV6 Display
Serial Programming Lead
This diagram is based on the original wiring recommended by ICS - the wire colours in your
system may differ. If in doubt, seek assistance from a professional installer.
If you have a printer attached, make sure it is switched off or disconnected
WHITE
BLACK
BLACK
SCREEN DRAIN
GREEN
RED
GND
A
B
TX
RX
GREEN (PROG)
RED (+V)
BLACK (GND)
WHITE (Rx)
BLUE (Tx)
NAV6 Printer (Optional)
Power Supply
GPS Sensor (Optional)
Display Cable Colours
YELLOW
WHITE
BLACK
NAV-6
DISPLAY
YELLOW
BLACK
SCREEN DRAIN
GREEN
RED
BLACK
BLUE
BLACK
BROWN
BLACK

ICS Nav6 Specifications

Power

voltage range	10.8V to 15.6V
standby power consumption	1.5 W at 12V
printing power consumption	2.5 W at 12V

Operating Environment

operating temperature range	0 to +40°C
storage temperature range	-20 to +55°C
humidity	0 to 95%

Weight and Dimensions

weight without cable	1200 g
paper roll width	80mm
paper roll length	20m
