ICT GP83 - Page 13

2-4. Large Paper Roll Fixed Mount Installation
1. Lock Large Paper Roll Fixed Mount on panel by four screws.
2. Hook two levers on Large Paper Roll Fixed Mount.
3. Let go of printer, when you hear “click”, the installation’s complete.
Chapter 2
11
www.ictgroup.com.tw
Figure 9
Figure 10
Figure 11
Click
