2.5" SATA Mobile Rack for PCI Slot
IB-2207 Series
http://www.icybox.de
54
6. LED Indication
Action LED Indication
Power on LED shines blue
HDD access LED blinks purple
7. Assembly of HDD and into PC
Attention!
a. Please connect the LED cable, which is delivered in the package. Otherwise the LED has no function!
b. When necessary please put on the "HDD-Pin-Protector" as shown in 7.1 to avoid mechanical
damage of the Pins.
7.1 7.2
7.3 7.4
LED: 4Pins
Data: 7Pins
Power: 15Pins
