Manual IB-872-i3
Product Information
The internal 4-port USB 3.0 card reader IB-872-i3 combines the most popular
memory cards in a clean and elegant way in the 3.5" bay of your desktop PC.
With this card reader the memory cards SD, microSD, CF and MS can be read
and written simultaneously. The additional USB 3.0 Type-A connection provides
even more flexibility and underlines the high connectivity of the IB-872-i3.
Package content: 1x IB-872-i3, 1x screw set, 1x manual
Key Features
• 4-port card reader with multi-LUN
• Additional USB 3.0 Type-A port
• Data transfer rates of up to 5 Gbit/s
• Supports 3.5" bay
• Supports SD 3.0/microSD 3.0/CF 6.0 /MS memory card
• Internal USB 3.0 20 pin connector
System requirements
One free 3.5" bay in your PC case, one free USB 3.0 20 pin connector on your
mainboard
Product overview
1. CF card slot
2. MS card slot
3. SD card slot
4. MicroSD card slot
5. Power LED (blue)
6. Access LED (green)
7. USB 3.0 Type-A port
1. 2.
3.
4. 5. 6. 7.
