Icy Box IB-PCI208-HS User Manual

Manual IB-PCI208-HS
Hint: Before you start the installation on the motherboard make sure that your body is electrically discharged.
Ground your body e.g. by touching a heating pipe. Discharge on contact with the motherboard can cause ir-
reparable damage.
Hint: Also make sure that the system is shut down and disconnected from the power supply before installing the
PCIe extension card
Please note the following important instructions for startup
• The M.2 SSD cannot be connected or disconnected while the computer is running.
• A new SSD must first be initialized, partitioned and formatted by the operating system to be
displayed by the system.
• If the SSD is not immediately recognized by the system, please check:
o whether the SSD is initialized, partitioned and formatted.
• PCIe M.2 SSDs become very warm when used. If you want to remove the SSD or PCIe card, wait
approx. 5-10 minutes after shutting down the system until the card has cooled down.
Fix the heat sink with the 4 small black screws (I) at all four
corners.
Depending on the PC case you use, fix the full- or
low-profile slot bracket with the big black screws (J).
5.
6.

Icy Box IB-PCI208-HS Specifications

General

Brand	Icy Box
Model	IB-PCI208-HS
Category	PCI Card
Language	English
