Icy Box IB-PCI208-HS User Manual

Manual IB-PCI208-HS
Product overview
No more free M.2 NVMe slot on your motherboard? No problem! Just use the ICY BOX IB-PCI208-HS on one
free PCIe x4 slot. With PCIe 4.0 x4 your M.2 NVMe SSD reaches the next level in data transfer rates. Up to 64
Gbit/s are supported with PCIe 4.0. In ranges like this your M.2 NVMe SSD needs to be cooled to avoid per-
formance lost. The delivered full aluminium heat sink ensures long term high-performance operations and provides
optimum heat dissipation thanks to the cooling fins.
Packing content:
• IB-PCI208-HS (A)
• Heat sink (B)
• Full-profile bracket (C)
• Low-profile bracket (D)
• Thick thermal pad (70 mm) (E)
• Thin thermal pad (70 mm) (F)
• Screw set (G/H/I/J)
• Screwdriver
• Manual
D
A
C
B
E F G
H
I
J

Icy Box IB-PCI208-HS Specifications

General

Brand	Icy Box
Model	IB-PCI208-HS
Category	PCI Card
Language	English
