Icy Box IB-RD3264+USE2 User Manual

14
4-bay RAID System with LCM Panel
IB-RD3264+USE2
http://www.icybox.de
15
NUMBER OF DISKS SUPPORTING
EACH RAID MODE
RAID Modes
Number of
Disk in RAID
RAID 0 (Striping) 2 to 4
RAID 1
(Mirroring)
2
Span 2 to 4
Clone 2 to 4
RAID 5 3 or 4
RAID 1+0 4
JBOD 1 to 4
LED INDICATORS
Indicators Color
Power on Green
Power off None
Indicators Color
Healthy None
Rebuild Blink Red
Broken Red
Degrade Red
Fan Error Red
Power LED x 1
Indicator
HDD (1, 2, 3, 4)
RAID mode
Left (Connection/
Access)
Right (Health)
Disk not detected None None All modes
Disk detected White None All modes
Disk not healthy White Red All modes
Data access Flash White None All modes
Disk
Rebuild
Source
HDD
White None
RAID 1, RAID 5,
RAID 1+0, Clone
Target
HDD
Flash White Blink Red
RAID
Alert
Blink Red
HDD LED x 8
RAID Alert LED x 1
