Icy Box IB-RD3621-C31 User Manual

Manual IB-RD3621-C31
3. 2.5" or 3.5" DRIVE INSTALLATION
Note!
Before installing the hard drive, please disconnect the power plug from the outlet. It may cause electric shock accident
or malfunction. When connecting the hard drive, please note the electrostatic! Body‘s static electricity may cause mal-
function of the device. Please touch a metal object to discharge or wear antistatic gloves before the operation.
Attention!
PCB of this device and HDDs are precision machinery, please be careful do not collision and
please notice the direction of HDD
Be careful the cutting edge inside may cut hand!
If hard disk already contains data, please backup data before installation to prevent data loss.
1. Detach the screws on the rear side. Slide the cover out to the back and then pull it up.
2. 3.5" drive 2.5" drive
2.1 Install the 3.5" drive gently 2.2 Firstly the 2.5" bracket must be installed on the 2.5" drive
as shown below and then into the main body!

Icy Box IB-RD3621-C31 Specifications

General

RAID levels	0, 1
Data transfer rate	6 Gbit/s
Storage drives installed	No
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD
Total installed storage capacity	0 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	0
Number of storage drives supported	2
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
USB connectivity	Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Chassis type	Desktop
Device class	Home & Home Office
Fan diameter	60 mm
Product color	Black
LED indicators	Access, Error, HDD
Number of fans	1 fan(s)
Housing material	Plastic
AC input voltage	100 - 240 V
DC output voltage	12 V
Country of origin	Taiwan
Harmonized System (HS) code	84717020
Cables included	USB Type-C

Weight and Dimensions

Depth	82 mm
Width	146 mm
Height	174 mm
Weight	498 g
