Make sure the device is connected to a Computer that is ON. To congure the RAID mode you want to use, the
Device has to be turned o. Please choose the RAID mode with the DIP-Switches shown as in the chart above.
Now press and hold the conrmation button while power on the device.
The HDD red indicators will be ashing and the RAID mode setup is completed. Now you just need to initialize
and format the drives and create a partition.
5 REPAIR OF A FAILED RAID1
HDD1 has failed
1. Turn o the power and then remove the failed HDD1.
2. Turn on the power, and wait a few seconds for the system to start up.
3. Install the new drive in the position of the removed HDD1 (the volume of the new HDD1 should be equal
the volume of the HDD2).
4. The rebuilding will start automatically. The left LED of the source drive (HDD2) lights purple. The LED of
the target drive (HDD1) lights red. This indicates that it is now rebuilding the RAID array.
5. Rebuilding of the RAID1 array will take several hours, depending on the drive capacity. When the data has
been restored, the HDD LEDs will turn a steady blue.
HDD2 has failed
1. Turn o the power and then remove the failed HDD2 (right).
2. Remove HDD1 (left) and put it into the slot of HDD2 (right).
3. Turn on the power, and wait a few seconds for the system to start up.
4. Install the new drive in the position of the slot of HDD1 (left) (the volume of the new HDD should be equal
the volume of the other HDD).
5. The rebuilding will start automatically. The left LED of the scource drive (HDD2) lights purple. The LED of
the target drive (HDD1) lights red. This indicates that it is now rebuilding the RAID array.
6. Rebuilding of the RAID1 array will take several hours, depending on the drive capacity. When the data has
been restored, the HDD LEDs will turn a steady blue.
Note: We recommend not turning o the power during the rebuild process but if the process is interrupted, it
will continue rebuilding the data as soon as the power is turned back on.
Note: If necessary, check the device manager and disc manager if the HDDs of the RAID1 array are working.
Note: If necessary, you need to assign a drive letter to the HDDs of the RAID1 array.
About data security
To protect your les and help prevent the loss of your data, we strongly recommend that you keep two copies of
your data, one copy on your IB-RD3621U3 and a second copy either on your internal drive or another storage
media such as CD, DVD, Tape or an additional external drive.
Any loss or corruption of data while using the IB-RD3621U3 is the sole responsibility of the user, and under no
circumstances will the manufacturer be held liable for compensation or the recovery of this data.
