Installation
• •
IDEAL 1071
The clamping device, with the attached knife
guard
A
, must be mounted on the trimmer
table before operating. To do this place the
knife guard
A
on the trimmer table. The knife
guard must be xed behind the knife guide
C
.
Then secure and tighten with the 2 enclosed
hex (A) head wrench screws (see picture).
For model IDEAL 1071 remove the protective
foil (B) on the knife guard.
IDEAL 1038 and IDEAL 1058:
Both of these models are delivered
completely assembled.
IDEAL 1071
