Functions Indication Table
Function Description
Power On Steady Greenlight in Tip,
2 Short Beeps
Power Off No Light, Long Beep
Tester Auto Power Off Green Light Flashes, 1 Beep
Audible OFF
(61-637 Only)
One Beep
Audible ON
(61-637 Only)
Two Beeps
Flashlight Button
(61-637 Only)
Flashlight On or Off
Electrical Specifications
Function Range
AC Voltage Sensing 61-637 24V AC to 600V AC
AC Voltage Sensing 61-627 50V AC to 600V AC
Frequency 50Hz or 60Hz AC
Environmental Specifications
Operating Temperature: 32ºF to 104ºF (0ºC to 40ºC) (<80%RH)
Operating Altitude:
6500 ft (2000 m)
Storage Temperature:
14ºF to 122ºF (-10ºC to 50ºC) (<80%RH)
15
Mechanical Specifications
Dimensions: (L x W x H) 6.0 in. x 1.0 in. x 1.1 in.
(154 mm x 26 mm x 29 mm)
Weight: 0.13 LBS (0.06 KG)
Power Source: (2) 1.5V AAA Batteries
Flashlight:
(61-637)
>500LUX @ 4 in
EMC/EMI
CISPR 22 3rd Edition. Class B Limits.
EN 55032
CISPR 32
CISPR 11
FCC 15. 107 with reference to Section 15.109 (g).
ICES-003
EN 61326-2-2 Sec 6.4.2.101
USA (FCC)
47 CFR 15 subpart B. This product is considered an exempt device per clause 15.103.
Safety
Complies with the following:
IEC 61010-1, Edition 3 (2010-06) +AMD1 (2016-12)
ANSI/UL/IEC EN 61010-1, Edition 3 (2016-04-29)
CSA-C22.2 No. 61010-1-12 Edition 3 (2019-07-19)
IEC 60529
Overvoltage CAT IV 600V.
Any voltages exceeding the defined maximum voltage measurement categories
described above are outside the normal use of the equipment and protection cannot
be guaranteed.
Pollution Degree Class 2
