IDEC GT3A Series

GT3W Series
Timers
835
USA: 800-262-IDEC Canada: 888-317-IDEC
Switches & Pilot Lights Display Lights Relays & Sockets Timers Terminal Blocks
Circuit Breakers
Part Number List
Part Numbers
Mode of Operation Output Contact Time Range* Rated Voltage Pin Confi guration New Part Numbers
A: Sequential Start
B: On-delay with course and fi ne
C: Recycler and instaneous
D: Recycler outputs (OFF Start)
E: Recycler outputs (ON Start)
F: Interval ON
G: Interval ON Delay
H: Sequential
Interval
3A, 240V AC
5A, 120V AC/30V DC
(Resistive Load)
Delayed
SPDT
+
Delayed
SPDT
1: 0.1sec - 6 hours
*(See Time Range Set-
tings for details.)
100 to 240V AC
(50/60Hz)
8 pin GT3W-A11AF20N
11 pin GT3W-A11EAF20N
24V AC/DC
8 pin GT3W-A11AD24N
11 pin GT3W-A11EAD24N
12V DC
8 pin GT3W-A11D12N
11 pin GT3W-A11ED12N
3: 0.1sec - 300 hours
100 to 240V AC
(50/60Hz)
8 pin
GT3W-A33AF20N
24V AC/DC GT3W-A33AD24N
1. For timing diagrams and schematics, see page 836.
2. For socket and accessory part number information, see page 838.
3. 8- and 11-pin models differ only in the number of pins (extra pins are not used).
4. For the timing diagram overview, see page 794.
5. *For details on setting time ranges, see the instructions on page 837.
Time Range Table
Time Range Code: 1 Time Range Code: 3
Time Range
Selector
Scale Time Range
Time Range
Selector
Scale Time Range
1S
0-1
0.1 sec - 1 sec 1S
0 - 3
0.1 sec - 3 sec
10S 0.3 sec - 10 sec 1M 3 sec - 3 min
10M 15 sec - 10 min 1H 3 min - 3 hours
1S
0 - 6
0.1 sec - 6 sec 1S
0 - 30
0.6 sec - 30 sec
10S 1 sec - 60 sec 1M 36 sec - 30 min
1M 6 sec - 6 min 1H 36min - 30 hours
10M 1 min - 60 min
10H 6 hours - 300 hours
1H 6 min - 6 hours
