3.5.2 Rotary Valve Exploded View
Packing
Gland
Air Inlet
Connector
Packing
Air Seal
End Cap
Packing
Gland
Screws
Infeed
Rotor
Shown
Packing Gland on
this End Cap
(Not shown)
Drive
Side
End
Cap
Drive
End
Body Air
Inlet
