3
Attach the dome cover to the bottom cover. Turn the
dome cover clockwise to fasten the dome cover.
4
Turn on power.
Bottom
Cover
Camera
Dome
Cover
Dimensions
Unit: mm (inch)
3 (0.11)
Ø 100 (3.93)
3 - Ø 4.2 (0.16) Hole
2 - M4 TAP
Ø 138 (5.43)
P.C.D. Ø 120 (4.72)
