5.3. Installation
Decide where to mount your 862-01-WFX-360-1B detector, mounting height should be
2.4m – 3.6m.
Set the jumper settings (seen in the Hardware section) to your needs. Leave the Walk
Test jumper ON to allow for testing.
Choose the Pulse Count you require by using the Pulse Count jumper (seen in the
Hardware section.)
Do a thorough Walk Test. Walk in the areas that require detection and make sure the
LED turns on for 2 seconds to indicate detection. Then walk in the areas that do not
require detection and make sure the LED does not turn on.
After completing your Walk Test take the Walk Test jumper off to exit Test Mode.
