IDS Optex Xwave

There are 16 zones of PIR detection on all angles except angle A and G, which only
have 14 zones of PIR detection. The red beams represent the PIR detection zone. The
blue line represents the microwave detection area.
Angle A Angle B
Angle C Angle D
Angle E Angle F
Angle G
