IDS Optex Xwave

9.2. Detection Area
The HX-40Ram has a detection range of up to 12
metres at an 85° angle. The detection area is
customisable with the use of Area Masking.
Supervision Jumper
J1 On – 90 mins
J1 Off – 12 hrs
IDS Wireless
Transmitter
Power Connector
Connect the battery
holder lead here.
Detector Inputs
Tamper & PIR inputs
come from the
detector.
Battery Holder
Holds 3 x CR 123A
batteries
